PI49FCT804T
Fast CMOS
Buffer/Clock Driver
Product Features
聲 Low output skew: 0.8ns
聲 Clock busing with Hi-Z state control
聲 TTL input and output levels, reducing problematic
聯ground bounce聰
聲 High output drive, I
OL
= 64mA
聲 Extremely low static power (1mW, typ.)
聲 Hysteresis on all inputs
聲 Packages available:
聳 16-pin 300 mil wide plastic SOIC (S)
聳 16-pin 150 mil wide QSOP (Q)
Product Description
Pericom Semiconductor聮s PI49FCT series of logic circuits are
produced using the Company聮s advanced 0.8 micron CMOS
technology, achieving industry leading speed grades.
The PI49FCT804T is a non-inverting clock driver designed with two
independent groups of buffers. These buffers have Hi-Z state
Output Enable inputs (active LOW) with a 1-in, 4-out configuration
per group. Each clock driver consists of two banks of drivers,
driving four outputs each from a standard TTL compatible CMOS
input.
Logic Block Diagram
OE
A
4
IN
A
OA
3
-OA
0
Product Pin Configuration
OA0
OA1
OA2
GND
1
2
3
4
5
6
7
8
16
15
VCC
OB0
OB1
OB2
GND
OB3
OEB
INB
16-Pin
P, S
14
13
12
11
10
9
4
IN
B
OE
B
OB
3
-OB
0
OA3
GND
OEA
INA
Product Pin Description
Pin N ame
O E
A
, O E
B
IN
A
, IN
B
O A
N
, O B
N
GN D
V
CC
C lock Inputs
C lock O utputs
Ground
Power
D e s cription
Hi- Z State O utput Enable Inputs (Active LO W)
Truth Table
(1)
Inputs
OE
A
, OE
B
L
L
H
H
IN
A
, IN
B
L
H
L
H
Outputs
OA
N
, OB
N
L
H
Z
Z
Note:
1. H = High Voltage Level
L = Low Voltage Level
Z = High Impedance
1
PS7005B
06/26/01
