PI3V314B Datasheet

  • PI3V314B

  • Low On-Resistance, 3.3V High-Bandwidth 3-Port, 4:1 Mux/DeMux...

  • 10頁

  • PERICOM   PERICOM

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PI3V314
Low On-Resistance, 3.3V High-Bandwidth
3-Port, 4:1 Mux/DeMux VideoSwitch
Features
鈥?Near-Zero propagation delay
鈥?5鈩?switches connect inputs to outputs
鈥?High signal passing bandwidth (375MHz)
鈥?Beyond Rail-to-Rail switching
鈥?5V I/O tolerant with 3.3V supply
鈥?2.5V and 3.3V supply voltage operation
鈥?Hot insertion capable
鈥?Low Crosstalk (X
TALK
= -60dB Typ.)
鈥?Low Off-Isolation (O
IRR
= -60db Typ.)
鈥?Industrial operating temperature: -40潞C to +85潞C
鈥?2KV ESD Protection (human body model)
鈥?Latch-up performance >250mA per JESD17
鈥?Packaging (Pb-free & greeen available):
鈥?40-Pin 150-mil wide plastic BQSOP(B)
Description
The PI3V314 is a true bi-directional 3-Port 4:1 multiplexer/
demultiplexer with Hi-Z outputs that is recommended for both RGB
and composite video switching applications. With the increased 4:
1 channels, multiple components, such as VCR, DVD, PC1, PC2
and etc. can be put on the video networks. The VideoSwitch can
be driven from a current output RAMDAC or voltage output com-
posite video source.
Low On-Resistance, Low Crosstalk, Low OFF Isolation and wide
bandwidth features make it ideal for video and other applications.
Industry leading advantages include a near zero propagation delay,
resulting from its low channel resistance and I/O capacitance. The
switch is bi-directional and offers little or no attenuation of the high-
speed signals at the outputs. The device also has exceptional high
current capability which is far greater than most analog switches
offered today. The PI3V314 offers a high-performance (375 MHz),
low-cost solution to switch between video sources.
Pin Configuration
NC
EN0
S
1
I
A
3
I
A
2
I
A
1
I
A
0
Applications
鈥?/div>
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
NC
V
CC
NC
S
0
I
B
3
I
B
2
I
B
1
I
B
0
Projection TV and LCD TV
鈥?Video consumer applications
鈥?Analog video signal processing
Pin Description
Pin Name
I
A
N
,
I
B
N
Description
Data Inputs
Select Inputs
Enable
Data Outputs
Ground
Power
Y
A
GND
NC
NC
EN1
S
3
I
C
3
I
C
2
I
C
1
I
C
0
Y
B
NC
NC
V
CC
NC
S
2
NC
NC
NC
NC
NC
NC
S
0-3
EN
0
to EN
1
Y
A
to Y
C
GND
V
CC
Y
C
GND
NC
Notes:
1. N.C = No internal connection
1
PS8756A
11/02/04
