General Purpose Relays
Miniature PCB Relay PE
I
I
I
I
I
I
I
I
1 pole 5 A, 1 CO or 1 NO contact
Cadmium-free contacts
Sensitive coil 200 mW
4 kV coil-contact
Ambient temperature 85擄C
Low height 10.0 mm
Plastic materials according to IEC60335-1 (domestic appliances)
RoHS compliant (Directive 2002/95/EC) as per product date
code 0352
F0169-B
Applications
Industrial electronics, white goods, measurement and control
Approvals
V
REG.-Nr.
of
6656,
Z
on request
(for version with 1 NO in process)
E214025
Technical data approved types
Contact data
Contact configuration
Contact set
Type of interruption
Rated current
Rated voltage / max.switching voltage AC
Maximum breaking capacity AC
Contact material
Mechanical endurance
Rated frequency of operation with / without load
Contact
Type
PE014
PE014
PE014
PE034
PE034
PE034
1 CO or 1 NO contact
single contact
micro disconnection
5A
240/400 VAC
1250 VA
AgNi90/10
15x10
6
cycles
6/1200 min
-1
ratings
Load
5 A, 250 VAC, resistive, 85擄C, 6 cycles/min, 50% df, EN61810-1
5 A, 30 VDC,resistive, on NO-contact, 85擄C, 6 cycles/min,
50% duty factor, EN61810-1,
5 A, 240 VAC resistive load, on NO or NC contact, UL508
5 A, 250 VAC, resistive, 85擄C, 6 cycles/min, 50% df, EN61810-1
5 A, 30 VDC,resistive, 85擄C, 6 cycles/min,
50% duty factor, EN61810-1,
5 A, 240 VAC resistive load, UL508
Cycles
1x10
5
1x10
5
1x10
5
1x10
5
1x10
5
1x10
5
Coil data
Rated coil voltage range DC coil
Coil power DC coil
Operative range
5...48 VDC
typ. 200 mW
2
Coil versions, DC-coil
Coil
Rated
Operate
Release
Coil
Rated coil
code
voltage
voltage
voltage
resistance
power
VDC
VDC
VDC
Ohm
mW
003
3
2.25
0.3
45+10%
200
005
5
3.8
0.5
125+10%
200
006
6
4.5
0.6
172+10%
209
012
12
9.0
1.2
685+10%
210
024
24
18.0
2.4
2725+10%
211
048
48
36.0
4.8
10970+10%
210
All figures are given for coil without preenergization, at ambient temperature +23擄C
Other coil voltages on request
1
Datasheet
Rev. GC1
Issued 2007/03
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information
only to be used together
with the 'Definitions' at
schrackrelays.com in the
鈥楽chrack鈥?section.
Specifications subject to
change.
