Overcurrent protection
OUTPUT VOLTAGE/CURRENT RATINGS CHART
Output #1
Model
PD65-10
PD65-12
PD65-13
PD65-14
PD65-25
PD65-30
PD65-31
PD65-32
PD65-40
NOTE:
Output #2
Output #3
Output #4
Vnom
5V
12V
15V
24V
+5V
+5V
Imin
0.0A
0.0A
0.0A
0.0A
1.0A
1.0A
Imax
10A
5.5A
4.5A
3.0A
6.0A
6.0A
Tol. Vnom Imin Imax Tol. Vnom Imin Imax Tol. Vnom Imin Imax Tol.
1%
1%
1%
1%
3% +24V 0.3A 2.0A 5%
3% +12V 0.5A 3.0A 5% 鈥?V 0.1A 0.5A 10%
Maximum
Output
Power
65W
65W
65W
65W
65W
65W
65W
65W
65W
+5V 1.0A 6.0A 3% +12V 0.5A 3.0A 5% 鈥?2V 0.1A 0.5A 10%
+5V 1.0A 6.0A 3% +15V 0.4A 3.0A 5% 鈥?5V 0.1A 0.5A 10%
+5V 1.0A 6.0A 3% +12V 0.5A 3.0A 5% 鈥?2V 0.1A 0.5A 10%
鈥?V
0.1A 0.5A 10%
1) All multi-output units may be operated at no load without damage. At no load, output tolerance increases to 10%.
2) Maximum output power for 10-30 VDC input range is 70% of that shown above.
3) Suffix codes for mechanical format and input range as follows:
Input voltage range
L: .10-30 VDC
Mechanical format:
A: PCB only
M: 20-60 VDC
C: Enclosed
H: 30-90 VDC
Example: PD65-31MC (20-60 VDC input range/Enclosed).
