PC87364 128-Pin LPC SuperI/O with Extended Wake-Up and Protection Support

PRELIMINARY

January 10, 1999

PC87364

128-Pin LPC SuperI/O with Extended Wake-Up and

Protection Support

General Description

The PC87364, a member of National Semiconductor鈥檚 128-

pin LPC SuperI/O family, introduces wake-up support for a

wide range of wake-up events, and new hardware and sof-

ware features to protect the system design. The PC87364

provides support for 51 GPIO ports, many with Assert

IRQ/SMI/PWUREQ capability. It is PC99 and ACPI compli-

ant, and offers a single-chip solution to the most commonly

used PC I/O peripherals.

The PC87364 also incorporates: Fan Speed Control and

Monitor (FSCM) for three fans, a Floppy Disk Controller

(FDC), a Keyboard and Mouse Controller (KBC), a full IEEE

1284 Parallel Port, two enhanced Serial Ports (UARTs), one

with Infrared (IR) support, an ACCESS.bus

廬

Interface

(ACB), System Wake-Up Control (SWC), General-Purpose

Input/Output (GPIO) support for 51 ports, Interrupt Serializer

for Parallel IRQs and an enhanced WATCHDOG鈩?timer.

Outstanding Features

鈥?/div>

Extended Wake-Up support, including legacy/ACPI

power button support, direct power supply control in

response to wake-up events, power-fail recovery

Protection features, including I/O access lock, chassis

hood lock/unlock, chassis intrusion detection, GPIO pin

attribute lock and pin configuration lock

Fan Speed Control and Monitor for three fans

Serial IRQ support (15 options)

Interrupt Serializer (11 Parallel IRQs to Serial IRQ)

Bus interface, based on Intel鈥檚

LPC Interface Speci鏗?

cation

Revision 1.0, September 29th, 1997

ACCESS.bus Interface, SMBus physical layer compatible

51 GPIO Ports (39 standard, including 23 with Assert

IRQ/SMI/PWUREQs interrupts; 12 V

-powered)

Blinking LEDs

128-pin PQFP Package

鈥?/div>

Block Diagram

Serial

Interface

Serial Infrared

Interface Interface

I/O

Ports

Floppy Drive

Interface

LPC Serial

Parallel Port

Interface

IRQ SMI

Interface

Serial Port 1

Serial Port 2

with IR

GPIO Ports

Floppy Disk

Controller

IEEE 1284

Parallel Port

Bus

Interface

BAT

System Wake-Up

Control

ACCESS.bus

Interface

WATCHDOG

Timer

Fan Speed

Control & Monitor

Keyboard &

Mouse Controller

Interrupt

Serializer

Power Wake-Up PWUREQ SCL

Control Events

SDA

WDO

3 Control 3 Monitor Keyboard Ports

Outputs

Inputs & Mouse I/F

Parallel

IRQs

ACCESS.bus廬 is a registered trademark of Digital Equipment Corporation.

I2C廬 is a registered trademark of Philips Corporation.

IBM廬, MicroChannel廬, PC-AT廬 and PS/2廬 are registered trademarks of International Business Machines Corporation.

Microsoft廬 and Windows廬 are registered trademarks of Microsoft Corporation.

TRI-STATE廬 is a registered trademark of National Semiconductor Corporation.

WATCHDOG鈥?is a trademark of National Semiconductor Corporation.

SMBus廬 is a registered trademark of Intel Corporation.

漏

1999 National Semiconductor Corporation

www.national.com
