CALIFORNIA MICRO DEVICES
PACUSB100
USB UPSTREAM PORT FILTER WITH ESD PROTECTION
Features
聲 Provides EMI/RFI filtering
聲 Bi-Directional ESD protection Circuitry for
optimum system protection
聲 Very small package
聲 USB 1.1 compliant
Applications
聲 Keyboard, mouse, game peripherals
聲 Speakers
聲 Scanners/printers
聲 Monitors
聲 Modems
Product Description
The USB is a four wire system utilizing a two wire twisted pair for transferring data, and two lines to supply power and ground
connection to hubs and devices. The USB allows for two modes of signaling. The low speed mode is defined at 1.5Mbs with
the full speed at 12Mbs.
The PACUSB100 provides ESD protection with EMI filtering and termination. It is ideal for protecting vulnerable components
in devices like keyboard, mouse, scanner/printer, etc. The PACUSB100 also supports upstream ports. California Micro Devices
also offers a complementary device (PACUSB200) to provide filtering and ESD protection for downstream ports. The PACUSB100
has the following characteristics:
聲
聲
聲
Compatible with Universal Serial Bus specification 1.0.
Protects both the system and device from external ESD pulses up to 6KV per the Human Body Model.
Suppresses EMI/RFI noise on high speed data lines.
Absolute Tolerance (33 OHM resistors)
Absolute Tolerance (1.5 ohm resistors)
Absolute Tolerance (47pF capacitors)
Operating Temperature Range
ESD Protection (Human Body Model)
MIL-STD -883, Method 3015
In System Protection (Note 1)
Package
STANDARD SPECIFICATIONS
鹵5%
鹵10%
鹵20%
0擄C to 70擄C
>4KV*
>6KV*
8 pin QSOP
SCHEMATIC CONFIGURATION
* Guaranteed by design
Note 1: Pins 1,4 and 8 grounded
Pins 3,5 and 6 open
Contact discharge between pins
7 and 2 to ground, one at a time
GND Pins = 1, 4, 8
STANDARD PART ORDERING INFORMATION
Package
Ordering Part Number
Pins
Style
Tubes
Tape & Reel
8
MSOP
PACUSB100MS/T
PACUSB100MS/R
Part Marking
U 10 0
