High temperature soldering: 250藲C/10 seconds at terminals
DEVICES FOR BIPOLAR APPLICATION
For Bidirectional use Suffix CA for types P4SMA6.8CA thru types
P4SMA550CA
Electrical characteristics apply in both directions
MAXIMUM RATINGS AND CHARACTERISTICS
@25藲C AMBIENT TEMPERATURE (unless otherwise noted)
PARAMETER
Peak pulse power Dissipation on
10/1000碌s waveform (Note 1.2,FIG.1)
Peak pulse current of on 10/1000碌s
waveform (Note 1, FIG.3)
Peak Forward Surge Current,
8.3ms Single Half Sine-Wave
Superimposed on Rated Load,
(JEDEC Method)(Note2,3)
Operating junction and Storage
Temperature Range
SYMBOL
PPPM
IPPM
VALUE
Min
400
See Table 1
UNIT
Watts
Agency Approvals:
Recognized under the Components Program
of Underwriters Laboratories.
Amps
Agency File Numbers
:
E128667
IFSM
40
Amps
ORDERING INFORMATION
P4SMA
C A
Tj, TsTG -55 to +150
擄C
Voltage
Bi-Directional
5% Voltage Tolerance
T = Tape and reeled (5000pcs)
Notes:
1. Non-repetitive current pulse, per Fig.3 and derated above
TA= 25藲C per Fig.2
2. Mounted on 5.0mm
2
(0.03mm thick) Copper Pads to each
terminal
3. 8.3ms single half sine-wave, or equivalent square wave,
Duty cycle = 4 pulses per minutes maximum
Mechanical Specifications:
Weight:
Case:
Mounting Position:
Polarity:
Terminal:
Standard Packaging:
0.002 ounce, 0.061 gram
JEDEC DO214AC. Molded plastic over
glass passivated junction
Any
Color band denoted positive end
(cathode) except Bidirectional
Solder plated, solderable per MIL-STD-
750, Method 2026
12mm tape (EIA STD RS-481)
258
