OSC-15802-810L Datasheet

  • OSC-15802-810L

  • Synchro/Resolver Reference Oscillator

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

OSC-15802
廬
SYNCHRO/RESOLVER/INDUCTOSYN
REFERENCE OSCILLATOR
DESCRIPTION
The OSC-15802 is a power oscillator
with two outputs that are 90擄 out of
phase. These outputs provide both
the reference and quadrature signals,
simultaneously, making the OSC-
15802 ideally suited for synchro,
resolver, Linear Variable Differential
Transformer (LVDT), Rotary Variable
Differential Transformer (RVDT) and
Inductosyn applications.
The oscillator鈥檚 outputs are pin-pro-
grammable for both frequency and
amplitude. The output frequency can
be programmed from 400 Hz to 10
kHz by simply connecting two exter-
nal capacitors. The Reference output
voltage, 7 Vrms, can be scaled down
by connecting a single resistor.
FEATURES
鈥?/div>
ADI Alternate Source
鈥?/div>
Quadrature Reference Output
Voltages for Inductosyn
Applications
APPLICATIONS
Packaged in an 18-pin hermetic DDIP,
the OSC-15802 operates over a tem-
perature range of -55擄C to +125擄C.
This, combined with its small size and
programmable output voltage and fre-
quency capabilities, makes it an
excellent choice for synchro, resolver,
LVDT, RVDT and Inductosyn applica-
tions.
鈥?/div>
Programmable Output Frequency
to 10 kHz
鈥?/div>
Small 18-Pin DDIP
鈥?/div>
Scalable Reference Output
鈥?/div>
-55擄C to +125擄C Operating
Temperature Range
G = +2.8
Cext
C1
+15 VDC
Rext
GND
-15 VDC
C2
QUAD OSCILLATOR
REF
OUT
5350
鈩?/div>
PA IN
-
PA OUT
+
Cext
REF OUT +90藲
FIGURE 1. OSC-15802 BLOCK DIAGRAM
漏
1981, 1999 Data Device Corporation
廬
Inductosyn is a registered trademark of Farrand Controls Corporation.
