OPA2342EA/250 Datasheet

  • OPA2342EA/250

  • Voltage-Feedback Operational Amplifier

  • 311.44KB

  • 11頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

OPA
434
2
OPA342
OPA2342
OPA4342
OPA
342
OPA
234
2
OPA
342
廬
OPA
434
2
www.ti.com
Low-Cost, Low-Power, Rail-to-Rail
OPERATIONAL AMPLIFIERS
Micro
Amplifier
鈩?/div>
Series
FEATURES
q
q
q
q
q
q
LOW QUIESCENT CURRENT: 150
碌
A typ
RAIL-TO-RAIL INPUT
RAIL-TO-RAIL OUTPUT (within 1mV)
SINGLE SUPPLY CAPABILITY
LOW COST
Micro
SIZE PACKAGE OPTIONS:
SOT23-5
MSOP-8
TSSOP-14
DESCRIPTION
The OPA342 series rail-to-rail CMOS operational
amplifiers are designed for low-cost, low-power, min-
iature applications. They are optimized to operate on
a single supply as low as 2.5V with an input common-
mode voltage range that extends 300mV beyond the
supplies.
Rail-to-rail input/output and high-speed operation make
them ideal for driving sampling Analog-to-Digital Con-
verters (ADC). They are also well suited for general-
purpose and audio applications and providing I/V con-
version at the output of Digital-to-Analog Converters
(DAC). Single, dual, and quad versions have identical
specs for design flexibility.
The OPA342 series offers excellent dynamic response
with a quiescent current of only 250碌A(chǔ) max. Dual and
quad designs feature completely independent circuitry
for lowest crosstalk and freedom from interaction.
SINGLE
OPA342
DUAL
OPA2342
QUAD
OPA4342
q
BANDWIDTH: 1MHz
q
SLEW RATE: 1V/
碌
s
q
THD + NOISE: 0.006%
APPLICATIONS
q
q
q
q
q
q
q
q
COMMUNICATIONS
PCMCIA CARDS
DATA ACQUISITION
PROCESS CONTROL
AUDIO PROCESSING
ACTIVE FILTERS
TEST EQUIPMENT
CONSUMER ELECTRONICS
PACKAGE
SOT23-5
MSOP-8
SO-8
TSSOP-14
SO-14
DIP-14
SPICE MODEL available at www.burr-brown.com.
Copyright 漏 2000, Texas Instruments Incorporated
SBOS106A
Printed in U.S.A. August, 2000

OPA2342EA/250 產品屬性

  • Texas Instruments

  • 運算放大器 - 運放

  • 2

  • 76 dB

  • 6 mV

  • 10 pA

  • 5.5 V

  • SMD/SMT

  • MSOP-8

  • 1 V/us

  • No

  • + 85 C

  • Reel

  • - 40 C

  • 250

  • 0.5 mA

  • 5.5 V

  • 2.7 V

  • CMOS

  • 124 dB
