OPA2691
OPA
OPA
268
268
1
1
SBOS224 鈥?DECEMBER 2001
Dual Wideband, Current Feedback
OPERATIONAL AMPLIFIER With Disable
FEATURES
q
q
q
q
q
q
q
q
FLEXIBLE SUPPLY RANGE: +5V to +12V
WIDEBAND +5V OPERATION: 230MHz (G = +2)
UNITY GAIN STABLE: 400MHz (G = 1)
HIGH OUTPUT CURRENT: 190mA
OUTPUT VOLTAGE SWING:
鹵
4.0V
HIGH SLEW RATE: 2100V/
碌
s
LOW SUPPLY CURRENT: 5.1mA/ch
LOW DISABLED CURRENT: 100
碌
A/ch
APPLICATIONS
q
q
q
q
q
q
q
q
xDSL LINE DRIVER / RECEIVER
MATCHED I/Q CHANNEL AMPLIFIER
BROADBAND VIDEO BUFFERS
HIGH SPEED IMAGING CHANNELS
PORTABLE INSTRUMENTS
DIFFERENTIAL ADC DRIVERS
ACTIVE FILTERS
WIDEBAND INVERTING SUMMING
DESCRIPTION
The OPA2691 sets a new level of performance for broadband dual
current feedback op amps. Operating on a very low 5.1mA/ch supply
current, the OPA2691 offers a slew rate and output power normally
associated with a much higher supply current. A new output stage
architecture delivers a high output current with minimal voltage
headroom and crossover distortion. This gives exceptional single-
supply operation. Using a single +5V supply, the OPA2691 can
deliver a 1V to 4V output swing with over 120mA drive current and
150MHz bandwidth. This combination of features makes the
OPA2691 an ideal RGB line driver or single supply Analog-to-Digital
Converter (ADC) input driver.
+12V
The OPA2691鈥檚 low 5.1mA/ch supply current is precisely trimmed at
25擄C. This trim, along with low drift over temperature, ensures lower
maximum supply current than competing products. System power
may be further reduced by using the optional disable control pin
(SO-14 only). Leaving this disable pin open, or holding it HIGH,
gives normal operation. If pulled LOW, the OPA2691 supply current
drops to less than 150碌A/ch while the output goes into a high
impedance state. This feature may be used for power savings.
OPA2691 RELATED PRODUCTS
SINGLES
Voltage Feedback
Current Feedback
Fixed Gain
OPA690
OPA691
OPA692
DUALS
OPA2690
OPA2681
OPA2682
TRIPLES
OPA3690
OPA3691
OPA3692
1/2
OPA2691
324鈩?/div>
12.4鈩?/div>
1:2
+6.5V
2Vp-p
2k鈩?/div>
1碌F
100鈩?/div>
15Vp-p
100鈩?/div>
324鈩?/div>
12.4鈩?/div>
2k鈩?/div>
1/2
OPA2691
Single Supply ADSL Upstream Driver
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCT PREVIEW information concerns products in the formative or
design phase of development. Characteristic data and other
specifications are design goals. Texas Instruments reserves the right to
change or discontinue these products without notice.
Copyright 漏 2001, Texas Instruments Incorporated
www.ti.com
OPA2691I-14D 產(chǎn)品屬性
50
集成電路 (IC)
Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
-
電流反饋
2
-
2100 V/µs
2GHz
280MHz
15µA
800µV
10.2mA
190mA
5 V ~ 12 V，±2.5 V ~ 6 V
-40°C ~ 85°C
表面貼裝
14-SOIC（0.154"，3.90mm 寬）
14-SOIC
管件
296-30906-ND - DEM-OPA-SO-3A296-22746-ND - BOARD DEMO FOR 14SOIC DUAL OPAMP
296-12436-5296-12436-5-NDOPA2691I14D
