Approved to DESC 5962-94520
Similar To OPA541
Isolated Hermetic Dual In-Line Package
Low Profile
Surface Mount Lead Form Available
FET Input
Power Supplies To 鹵40V
DESCRIPTION
These devices are designed specifically for electronic assemblies requiring low profile
package types. The OMA541SF is a monolithic operational amplifier capable of
operating from power supplies up to 鹵40V and peak currents of up to 2 amps. The
packaging provides the ultimate in size, thermal performance and ease of assembly.
It is ideally suited for high density electronic assemblies and is approved to DESC
drawing 5962-94520.
ABSOLUTE MAXIMUM RATINGS
@ 25擄C
Supply Voltage, +V
S
to -V
S
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80V
Output Current, Peak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.0A
Output Current, Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5A
Power Dissipation, Internal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25W
Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55擄C to 125擄C
Storage Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55擄C to 150擄C
Maximum Junction Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175擄C
Lead Temperature (10 Sec. Soldering) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300擄C
SCHEMATIC
+V
S
3.4
-In
+In
Current
Sense
R
CL
Output
Drive
(ext.)
Output
-V
S
4 11 R0
3.4 - 37
1
2
3
4
