E2V0017-37-X1

隆 electronic components

OL5204N-50/P

LASER DIODES

1.55

mm

High-Power DIP Module with 9mm Profile

OL5204N-50/P

GENERAL DESCRIPTION

The OL5204N-50/P is a 1.55

mm

high-power laser in a 14-pin DIL package with 9mm profile.

Having extreme high-power in pulsed condition, this device can be used in an optical

measurement equipment like OTDR systems.

FEATURES

鈥?Fiber output power: Pf=50 mW (pulse width 10

ms,

duty ratio 1 %)

鈥?Cooled DIL Package, 9mm hight

APPLICATIONS

鈥?Optical measurement equipment

鈥?OTDR

PACKAGE DIMENSIONS (Unit: mm)

鈥?OL5204N-50/P

5

f0.9

1

25.4

12.7

1.0

20.8

24

5.9

7.1

9

3.8

2.54

f0.45

TERMINAL CONNECTION

(BOTTOM VIEW)

#8

#14

(鈥?

LD

THERMISTOR

CASE

COOLER

6.35

FIBER

(+)

#7

#1

PIN No.

1

2

3

4

5

6

7

FUNCTION

COOLER ANODE

NC

NC

NC

LD ANODE and

CASE GROUND

NC

NC

PIN No.

FUNCTION

NC

8

LD CATHODE

9

LD ANODE and

10

CASE GROUND

THERMISTOR

11

THERMISTOR

12

NC

13

COOLER CATHODE

14

7.62

19

1/3
