E2V0038-37-X2

隆 electronic components

OE3202G-004, OE3202G-010

EDGE EMITTING DIODES

1.3

mm

Edge-Emitting LED DIP Module

OE3202G-004, OE3202G-010

GENERAL DESCRIPTION

The OE3202G-004 and OE3202G-010 are 1.3

mm,

edge-emitting LED DIP modules with single-

mode fiber pigtails. The OKI EE-LED (OE3202G-010) features high coupling efficiency, achieving

a single-mode fiber output of over 100

mW.

The modules are optimal light sources for optical

LAN systems and measuring instruments.

FEATURES

鈥?High output power : Pf=40

mW

(OE3202G-004)

: Pf=100

mW

(OE3202G-010)

鈥?Single-mode fiber

鈥?Hermetically-sealed, 14-pin Dual-In-line Package (DIP)

鈥?Includes thermoelectric cooler for temperature control

鈥?High speed

APPLICATIONS

鈥?LANs

鈥?Optical measuring instruments

鈥?Data communication systems

PACKAGE DIMENSIONS (Unit: mm)

鈥?OE3202G-004, OE3202G-010

5

f0.9

1

25.4

12.7

1.0

20.8

24

5.9

7.1

9

3.8

2.54

f0.45

TERMINAL CONNECTION

(BOTTOM VIEW)

#8

#14

(鈥?

EE-LED

THERMISTOR

CASE

COOLER

6.35

FIBER

(+)

#7

#1

PIN No.

1

2

3

4

5

6

7

FUNCTION

COOLER ANODE

NC

NC

NC

EE-LED ANODE,

CASE GROUND

and THERMISTOR

NC

NC

PIN No.

FUNCTION

NC

8

EE-LED CATHODE

9

EE-LED ANODE,

10

CASE GROUND

and THERMISTOR

THERMISTOR

11

NC

12

NC

13

COOLER CATHODE

14

7.62

19

1/4
