OD-J6500-0B01/HB01, OD-J6502-0B01/HB01
OD-J8510-0B01
156Mbps Optical Transmitter
for SONET/SDH Systems
FEATURES
n
n
n
n
n
n
n
Designed for SONET /SDH /ATM Systems.
Reflow Solder able SMT Package.
Compact Size: 26 x 10 x 3 (mm).
Low Power Consumption: 0.3W (Typ.).
Single +3.3V Power Supply.
Wide Operating Temperature Range.
Long Distance Transmission.
APPLICATION
Part Number
OD-J6500-0B01 / HB01
OD-J6502-0B01 / HB01
OD-J8510-0B01
Specification
SONET OC-3 SR / IR-1
ITU-T G. 957 I-1 / S-1.1
SONET OC-3 LR-1
ITU-T G. 957 L-1.1
SONET OC-3 LR-2 / LR-3
ITU-T G. 957 L-1.2 / L-1.3
OPERATING CONDITIONS
Parameter
Case Temperature.
Power Supply Voltage
Power Consumption
OD-J650x-xB01
OD-J8510-0B01
OD-Jxxxx-0B01
OD-Jxxxx-HB01
Uni
t
o
C
V
W
Min.
0
-40
+3.135
-
-
Values
Typ.
-
-
+3.30
0.3
T.B.D.
Max.
+75
+85
+3.465
0.6
T.B.D.
