NSQA12VAW5T2G Datasheet

  • NSQA12VAW5T2G

  • Low Capacitance Quad Array for ESD Protection

  • 47.71KB

  • 4頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NSQA6V8AW5T2 Series
Low Capacitance
Quad Array for
ESD Protection
This integrated transient voltage suppressor device (TVS) is
designed for applications requiring transient overvoltage protection. It
is intended for use in sensitive equipment such as computers, printers,
business machines, communication systems, medical equipment, and
other applications. Its integrated design provides very effective and
reliable protection for four separate lines using only one package.
These devices are ideal for situations where board space is at a
premium.
Features
http://onsemi.com
1
2
3
5
4
鈥?/div>
ESD Protection: IEC61000鈭?鈭?: Level 4
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
MILSTD 883C 鈭?Method 3015鈭?: Class 3
Four Separate Unidirectional Configurations for Protection
Low Leakage Current < 1
mA
Power Dissipation: 380 mW
Small SC鈭?8A SMT Package
Low Capacitance
Pb鈭扚ree Package is Available
SC鈭?8A/SOT鈭?23
CASE 419A
Benefits
MARKING DIAGRAM
4
6x
1
x
D
2
5
D
3
鈥?/div>
Provides Protection for ESD Industry Standards: IEC 61000, HBM
鈥?/div>
Protects the Line Against Transient Voltage Conditions in Either
Direction
鈥?/div>
Minimize Power Consumption of the System
鈥?/div>
Minimize PCB Board Space
Typical Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Instrumentation Equipment
Serial and Parallel Ports
Microprocessor Based Equipment
Notebooks, Desktops, Servers
Cellular and Portable Equipment
= H for NSQA6V8AW5T2
X for NSQA12VAW5T2
= One Digit Date Code
ORDERING INFORMATION
Device
NSQA6V8AW5T2
NSQA6V8AW5T2G
Package
SC鈭?8A
Shipping
鈥?/div>
3000/Tape & Reel
SC鈭?8A 3000/Tape & Reel
(Pb鈭扚ree)
SC鈭?8A
3000/Tape & Reel
NSQA12VAW5T2
NSQA12VAW5T2G
SC鈭?8A 3000/Tape & Reel
(Pb鈭扚ree)
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
漏
Semiconductor Components Industries, LLC, 2004
1
November, 2004 鈭?Rev. 3
Publication Order Number:
NSQA6V8AW5T2/D

NSQA12VAW5T2G 產品屬性

  • 1

  • 過電壓，電流，溫度裝置

  • TVS - 二極管

  • -

  • 9V

  • 11.4V

  • 20W

  • 4 通道陣列 - 單向

  • 表面貼裝

  • 6-TSSOP（5 引線），SC-88A，SOT-353

  • SOT-353

  • 剪切帶 (CT)

  • NSQA12VAW5T2GOSCT
