Description
The NPP Series features silicon pressure sensors in
surface mount packages. An ultra-small Silicon
Fusion Bonded (SFB), ultra-high stability
SenStable廬 piezoresistive chip from GE
NovaSensor廬 is placed in a plastic package that
exploits high volume, leadframe package technol-
ogy to bring forth a low-cost sensor alternative to
the OEM user.
With constant voltage excitation, the NPP-301
produces a voltage output that is linearly propor-
tional to the input pressure. The user can provide
NPP Series products with signal conditioning cir-
cuitry to amplify the output signal or to maximize
OEM value added. The NPP Series is compatible
with most noncorrosive gases and dry air.
Product Data Sheet
GE NovaSensor
Schematic Diagram
+IN
8
+OUT
2
6
鈥揙UT
4
鈥揑N
5
鈥揑N
Package Diagram
0.08
NPP-301
Series
Surface Mount
Pressure Sensor
NPP-301A
0.06
N/C
+OUT
0.03
HOLE
8
+IN
7
N/C
6
鈥揙UT
5
鈥揑N
0.05
TYP.
0.20
0.016
TYP.
1
2
3
N/C
鈥揑N
4
0.16
0.24
0.07
Features
鈥?Low-cost surface mount package: SO-8
鈥?Wide operating temperature range:
鈥?0 to +125擄C
鈥?Static accuracy < 0.20% FSO maximum
鈥?Suitable for automated component assembly
鈥?Four element Wheatstone bridge configuration
for circuit design flexibility
鈥?Solid-state reliability
鈥?100, 200 and 700 kPa absolute pressure
ranges available
0.01
0.02
0.08
0.03
HOLE
8
+IN
2
+OUT
3
N/C
鈥揑N
4
0.16
0.24
0.08
5
6
鈥揙UT
鈥揑N
7
N/C
0.11
0.01
NPP-301B
0.06
1
N/C
0.05
TYP.
0.20
0.016
TYP.
0.06
0.07
0.01
0.02
0.11
0.01
Note: All dimensions are in inches
How to Order
Applications
鈥?Automotive Tire Pressure
鈥?Pneumatic Controls
鈥?Pressure Switches and Controllers
鈥?Altimeters and Barometers
鈥?Cable Leak Detection
鈥?Consumer Appliances
鈥?Portable Gages and Manometers
Part Number
NPP-301A-100A
NPP-301A-200A
NPP-301A-700A
NPP-301A-100AT
NPP-301A-200AT
NPP-301A-700AT
NPP-301B-100A
NPP-301B-200A
NPP-301B-700A
NPP-301B-100AT
NPP-301B-200AT
NPP-301B-700AT
Description
Shipping
15 psia, non-ported IC tubes
30 psia, non-ported IC tubes
100 psia, non-ported IC tubes
15 psia, non-ported tape & reel
30 psia, non-ported tape & reel
100 psia, non-ported tape & reel
15 psia, ported
30 psia, ported
100 psia, ported
15 psia, ported
30 psia, ported
100 psia, ported
IC tubes
IC tubes
IC tubes
tape & reel
tape & reel
tape & reel
