Select Pin Compatible with TTL Levels
Channel Select Input Over鈥揤oltage Tolerant to 5.5 V
Fast Switching and Propagation Speeds
Break鈥揃efore鈥揗ake Circuitry
Low Power Dissipation: I
CC
= 2
mA
(Max) at T
A
= 25擄C
Diode Protection Provided on Channel Select Input
Improved Linearity and Lower ON Resistance over Input Voltage
Latch鈥搖p Performance Exceeds 300 mA
ESD Performance: HBM > 2000 V; MM > 200 V
Chip Complexity: 38 FETs
SC鈥?0/SC鈥?8/SOT鈥?63
DF SUFFIX
CASE 419B
AO
d
1
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section of this data sheet.
SELECT
1
V
+
2
GND
3
6
5
4
NO
COM
NC
FUNCTION TABLE
Figure 1. Pin Assignment
Select
L
H
ON Channel
NC
NO
2X1
COM
U
Figure 2. Logic Symbol
漏
Semiconductor Components Industries, LLC, 2002
April, 2002 鈥?Rev. 5
U
U
CHANNEL SELECT
2X0
NO
NC
1
Publication Order Number:
NLAST4599/D
