NLAS1053US Datasheet

  • NLAS1053US

  • 2:1 Mux/Demux Analog Switches

  • 12頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NLAS1053
2:1 Mux/Demux Analog
Switches
The NLAS1053 is an advanced CMOS analog switch fabricated
with silicon gate CMOS technology. It achieves very high speed
propagation delays and low ON resistances while maintaining CMOS
low power dissipation. The device consists of a single 2:1
Mux/Demux (SPDT), similar to ON Semiconductor鈥檚 NLAS4053
analog and digital voltages that may vary across the full power supply
range (from VCC to GND).
The inhibit and select input pins have over voltage protection that
allows voltages above VCC up to 7.0 V to be present without damage
or disruption of operation of the part, regardless of the operating
voltage.
http://onsemi.com
MARKING
DIAGRAMS
8
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
High Speed: tPD = 1 ns (Typ) at VCC = 5.0 V
Low Power Dissipation: ICC = 2
碌A(chǔ)
(Max) at TA = 25擄C
High Bandwidth, Improved Linearity, and Low RDSON
INH Pin Allows a Both Channels 鈥極FF鈥?Condition (With a High)
RDSON
鈮?/div>
25
鈩?/div>
, Performance Very Similar to the NLAS4053
Break Before Make Circuitry, Prevents Inadvertent Shorts
Useful For Switching Video Frequencies Beyond 50 MHz
Latch鈥揢p Performance Exceeds 300 mA
ESD Performance: HBM
>
2000 V; MM
>
200 V, CDM
>
1500 V
Tiny US8 Package, Only 2.1 X 3.0 mm
US8
US SUFFIX
CASE 493鈥?1
AC
1
D
AC
D
= Device Code
= Date Code
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 9 of this data sheet.
COM
1
INH
2
N/C
3
GND
4
8
7
6
5
VCC
CH0
CH1
Select
INH
H
L
L
FUNCTION TABLE
Select
X
L
H
Ch 0
OFF
ON
OFF
Ch 1
OFF
OFF
ON
Figure 1. Pin Assignment
漏
Semiconductor Components Industries, LLC, 2002
1
February, 2002 鈥?Rev. 0
Publication Order Number:
NLAS1053/D

NLAS1053US 產品屬性

  • 3,000

  • 集成電路 (IC)

  • 接口 - 模擬開關，多路復用器，多路分解器

  • -

  • 開關

  • 1 x SPDT

  • 22 歐姆

  • 單電源

  • 2 V ~ 5.5 V

  • 1µA

  • -55°C ~ 125°C

  • 表面貼裝

  • 8-VFSOP（0.091"，2.30mm 寬）

  • US8

  • 帶卷 (TR)

  • NLAS1053USOSTR
