External Reference Type Ku-band PLL LNB
NJR2633E / EN0
MODEL NO.
NJR2634E / EN0
MODEL NO.
NJR2635E / EN0
MODEL NO.
NJR2636E / EN0
MODEL NO.
NJR2637E / EN0
MODEL NO.
NJR2639E / EN0
MODEL NO.
<Description>
This specification defines the Low Noise Block downconverter (LNB) intended for the satellite data communication
downlink application in the Ku-band. This LNB has a combined 3-stage HEMT amplifier and block downconverter
with Phase Locked Local, which is constituted with a VCO, SPD (Sampling Phase Detector), Loop Filter and
Reference Recovery VCXO providing low phase noise. All specifications shall apply throughout the full range of the
specified environmental conditions unless otherwise specified.
<Line-Up>
Model No.
NJR2637E / EN0
NJR2639E / EN0
NJR2633E / EN0
NJR2635E / EN0
NJR2634E / EN0
NJR2636E / EN0
RF Frequency
10.95 to 11.70 GHz
11.20 to 11.70 GHz
11.45 to 11.95 GHz
11.70 to 12.20 GHz
12.20 to 12.70 GHz
12.25 to 12.75 GHz
Local Frequency
10.00 GHz
10.25 GHz
10.50 GHz
10.75 GHz
11.25 GHz
11.30 GHz
Local Stability
IF Frequency
950 to 1,700 MHz
950 to 1,450 MHz
950 to 1,450 MHz
950 to 1,450 MHz
950 to 1,450 MHz
950 to 1,450 MHz
Depends on
External reference
<Specifications>
Item
Input Waveguide Flange
Output Connector
Specifications
WR75
Type F-female (75 ohm)
<Model No. NJR2633E / 34E / 35E / 36E / 37E / 39E >
Type N-female (50 ohm)
<Model No. NJR2633EN0 / 34EN0 / 35EN0 / 36EN0 / 37EN0 / 39EN0 >
Option1: N-male, Option2: TNC female
0.9 dB typ.
55 dB min. 60 dB typ.
2 dB max.
In any 50 MHz segment over the frequency band.
+10 dBm min.
-63 dBc/Hz at 100 Hz
-73 dBc/Hz at 1 kHz
-83 dBc/Hz at 10 kHz
-93 dBc/Hz at 100 kHz
10 MHz
-10 to 0 dBm (75ohm or 50 ohm) @ IF output connector
IF output connector (combine reference with IF signal)
-135 dBc/Hz at 100Hz
-143 dBc/Hz at 1kHz
-145 dBc/Hz at 10kHz
(Input Condition)
-140 dBm max.
At input, fixed frequency spurious, unrelated to test CW signal.
-50 dBc max. With test CW signal -10dBm IF output.
(measured at specified IF band ; 950 to 1,450 MHz or 1,700MHz)
Rev.04 External Ku-PLL LNB
Noise Figure
(at 25 擄C)
Conversion Gain (at 25 擄C)
Conversion Gain Variation
(at 25 擄C)
P1dB
Phase Noise (SSB)
External Reference Input Frequency
External Reference Input Power
External Reference Input Port
External Reference Phase Noise
Spurious
Copyright 漏 1999 New Japan Radio Co., Ltd.
