NJM2575

LOW VOLTAGE VIDEO AMPLIFIER WITH LPF

sGENERAL

DESCRIPTION

The NJM2575

is a Low Voltage Video Amplifier contained LPF circuit,

75鈩?driver to connect TV monitor directly.

The mute circuit with power save function is suitable for low power

design. The NJM2575 is suitable for down

NJM2575F1

sPACKAGE

OUTLINE

sFEATURES

qOperating

Voltage

2.8 to 5.5V

qInput

Composite Video Signal 1.0Vpp

qInternal

Low Pass Filter

qOperating

Current

7.0mA typ. at Vcc=3.0V

qOperating

Current Power Save Mode 60uA typ.at Vcc=3.0V

qBipolar

Technology

qPackage

Outline

MTP6

sBLOCK

DIAGRAM

V

+

6

6dB

Vin

4

CLAMP

LPF

75鈩?Driver

2

3

Vout

Vsag

5

GND

1

Power Save

-1-
