NCV7701
2.0 Amp H鈭払ridge Driver
This automotive grade H鈭払ridge driver provides a flexible means
for controlling loads requiring bidirectional drive currents. Bridge
outputs are protected from overcurrent at each switch and
overtemperature shutdown provides product robustness. The
NCV7701 inputs can be interfaced to a range of voltages, including
vehicle battery voltage. The product features a low quiescent current
mode, allowing unswitched connection to the power source. The
NCV7701 is produced using ON Semiconductor鈥檚 POWERSENSEt
BCD technology.
Features
http://onsemi.com
SO鈭?0L
DW SUFFIX
CASE 751D
1
20
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
MARKING DIAGRAM
20
NCV7701
AWLYYWW
1
A
WL, L
YY, Y
WW, W
= Assembly Location
= Wafer Lot
= Year
= Work Week
Forward, Reverse, Brake High, Brake Low Modes
1.0 A Output Current Capability (DC)
Supply Voltage Range 7.0 V to 26 V
0.25
鈩?/div>
R
DS(ON)
per Driver @ 25擄C
Sleep Mode (I
Q
< 10
碌A(chǔ))
Overvoltage Protection
Thermal Protection
Undervoltage Disable Function
Short Circuit Protection
Cross Conduction Protection
Synchronous Low鈭扴ide Rectification for Lower Power Dissipation
Diagnostic Output (Open Drain)
TTL/CMOS/Pull鈭扷p to Battery Compatible Inputs
20 Lead SO Package with 8 Internally Fused Leads
PIN CONNECTIONS
1
V
BAT
NC
OUTB
GND
GND
GND
GND
FAULT
NC
NC
20
NC
NC
OUTA
GND
GND
GND
GND
EN
IN1
IN2
Typical Applications
鈥?/div>
DC Motors
鈥?/div>
Stepper Motors
鈥?/div>
Modulator Valves
ORDERING INFORMATION
Device
NCV7701DW
NCV7701DWR2
Package
SO鈭?0L
SO鈭?0L
Shipping鈥?/div>
37 Units/Rail
1000 Tape & Reel
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
漏
Semiconductor Components Industries, LLC, 2003
1
October, 2003 鈭?Rev. 3
Publication Order Number:
NCV7701/D
