NCP612, NCV612
100 mA CMOS Low Iq
Voltage Regulator in an
SC70鈭?
The NCP612/NCV612 series of fixed output linear regulators are
designed for handheld communication equipment and portable battery
powered applications which require low quiescent. The
NCP612/NCV612 series features an ultra鈭抣ow quiescent current of
40
mA.
Each device contains a voltage reference unit, an error
amplifier, a PMOS power transistor, resistors for setting output
voltage, current limit, and temperature limit protection circuits.
The NCP612/NCV612 has been designed to be used with low cost
ceramic capacitors. The device is housed in the micro鈭抦iniature
SC70鈭? surface mount package. Standard voltage versions are 1.5,
1.8, 2.5, 2.7, 2.8, 3.0, 3.3, and 5.0 V.
Features
http://onsemi.com
MARKING
DIAGRAM
SC70鈭?/SC鈭?8A/
SOT鈭?53
SQ SUFFIX
CASE 419A
5
1
xxxd
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Low Quiescent Current of 40
mA
Typical
Low Dropout Voltage of 300 mV at 100 mA
Low Output Voltage Option
Output Voltage Accuracy of 2.0%
Temperature Range of 鈭?0擄C to 85擄C (NCP612)
Temperature Range of 鈭?0擄C to 125擄C (NCV612)
鈥?/div>
NCV Prefix for Automotive and Other Applications Requiring Site
and Control Changes
鈥?/div>
Pb鈭扚ree Packages are Available
Typical Applications
xxx = Specific Device Code
d = Date Code
PIN CONNECTIONS
V
in
Gnd
Enable
1
2
3
(Top View)
4
N/C
5
V
out
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Cellular Phones
Battery Powered Consumer Products
Hand鈭扝eld Instruments
Camcorders and Cameras
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 9 of this data sheet.
Battery or
Unregulated
Voltage
Vout
C1
+
1
2
5
+
C2
ON
OFF
3
4
This device contains 86 active transistors
Figure 1. Typical Application Diagram
漏
Semiconductor Components Industries, LLC, 2005
1
April, 2005 鈭?Rev. 0
Publication Order Number:
NCP612/D
