NCP5332ADW Datasheet

  • NCP5332ADW

  • Two-Phase Buck Controller with Integrated Gate Drivers and 5...

  • 30頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP5332A
Two鈭扨hase Buck Controller
with Integrated Gate
Drivers and 5鈭払it DAC
The NCP5332A is a second鈭抔eneration, two鈭抪hase step down
controller which incorporates all control functions required to power
high performance processors and high current power supplies.
Proprietary multi鈭抪hase architecture guarantees balanced load current
distribution and reduces overall solution cost in high current
applications. Enhanced V
2
鈩?/div>
control architecture provides the fastest
possible transient response, excellent overall regulation, and ease of
use. The NCP5332A is a second鈭抔eneration PWM controller because
it optimizes transient response by combining traditional Enhanced V
2
with an internal PWM ramp and fast鈭抐eedback directly from V
CORE
to
the internal PWM comparator. These enhancements provide greater
design flexibility, facilitate use and reduce output voltage jitter.
The NCP5332A multi鈭抪hase architecture reduces output voltage
and input current ripple, allowing for a significant reduction in filter
size and inductor values with a corresponding increase in inductor
current slew rate. This approach allows a considerable reduction in
input and output capacitor requirements, as well as reducing overall
solution size and cost.
Features
鈥?/div>
Enhanced V
2
Control Method with Internal Ramp
鈥?/div>
Internal PWM Ramp
鈥?/div>
Fast鈭扚eedback Directly from V
CORE
鈥?/div>
VRM 9.X DAC with 1.0% Accuracy
鈥?/div>
Adjustable Output Voltage Positioning
鈥?/div>
4 On鈭払oard Gate Drivers
鈥?/div>
200 kHz to 800 kHz Operation Set by Resistor
鈥?/div>
Current Sensed through Buck Inductors or Sense Resistors
鈥?/div>
Hiccup Mode Current Limit
鈥?/div>
Individual Current Limits for Each Phase
鈥?/div>
On鈭払oard Current Sense Amplifiers
鈥?/div>
3.3 V, 1.0 mA Reference Output
鈥?/div>
5 V and 12 V, or 12 V Only Operation
鈥?/div>
On/Off Control (through Soft Start Pin)
鈥?/div>
Power Good Output with Internal Delay
http://onsemi.com
28
1
SO鈭?8L
DW SUFFIX
CASE 751F
PIN CONNECTIONS AND
MARKING DIAGRAM
1
COMP
V
FB
V
DRP
CS1
CS2
CS
REF
PWRGD
V
ID0
V
ID1
V
ID2
V
ID3
V
ID4
I
LIM
REF
A
WL, L
YY, Y
WW, W
28
R
OSC
V
CCL
V
CCL1
GATE(L)1
GND
GATE(H)1
V
CCH1
LGND
SS
V
CCL2
GATE(L)2
GND2
GATE(H)2
V
CCH2
= Assembly Location
= Wafer Lot
= Year
= Work Week
ORDERING INFORMATION
Device
NCP5332ADW
NCP5332ADWR2
Package
SO鈭?8L
SO鈭?8L
Shipping
26 Units/Rail
1000 Tape & Reel
NCP5332A
AWLYYWW
漏
Semiconductor Components Industries, LLC, 2003
1
August, 2003 鈭?Rev. 4
Publication Order Number:
NCP5332A/D

NCP5332ADW 產品屬性

  • 26

  • 集成電路 (IC)

  • PMIC - 穩壓器 - 專用型

  • -

  • 控制器，高性能處理器

  • 4.5 V ~ 14 V

  • 2

  • 可調

  • 0°C ~ 70°C

  • 表面貼裝

  • 28-SOIC（0.295"，7.50mm 寬）

  • 28-SOIC

  • 管件
