NCP4672DR2G Datasheet

  • NCP4672DR2G

  • Dual Linear Voltage Regulators with Vin and Vout Voltage Det...

  • 8頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP4672
Dual Linear Voltage
Regulators with V
in
and V
out
Voltage Detector
The NCP4672 is a dual linear voltage regulator with input voltage
and output voltage detectors. This part is useful in systems where
multiple voltages are required such as for core and I/O. The NCP4672
is very accurate at 2% over full input voltage and full load current. The
NCP4672 eliminates the need for external voltage supervision due to
the two built in voltage detectors. The voltage detector on the input is
set to 7.0 V. The output voltage detector is for channel 1 and is set to
2.9 V. An external capacitor is used to set the duration of this reset
signal. Other features include short circuit protection and thermal
shutdown protection. The NCP4672 has been designed to work with a
4.7
mF
output capacitor having an ESR between 0.1
W
and 5.0
W.
Features
http://onsemi.com
MARKING
DIAGRAM
8
8
1
SOIC鈭?
NB SUFFIX
CASE 751
1
4672G
A
L
YW
= Specific Device Code
= Assembly Location
= Wafer Lot
= Date Code
4672G
ALYW
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Accuracy: 2% at Full Voltage and Load
Excellent Ripple Rejection: 70 dB @ 1 kHz
Voltage Detector for Input Voltage
Voltage Detector for Output Voltage
Programmable Delay of Reset Signal
Thermal Short Circuit Protection
This is a Pb鈭扚ree Device
PIN CONFIGURATION
V
in
Rst 1
V
out
Rst 2
8 V
out1
7 GND1
6 GND2
5 V
out2
(Top View)
Typical Application
Small Core and I/O Power
Consumer Equipment
Measurement Equipment
Industrial Equipment
V
in
RST
10 KW
C
D
3
V
in
4
ORDERING INFORMATION
V
in
Rst
V
out1
GND2
V
out2
V
out2
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
V
out1
C
out2
4.7
mF
Device
NCP4672DR2G
Package
SOIC鈭?
(Pb鈭扚ree)
Shipping
鈥?/div>
2500 Tape & Reel
V
in
V
out
Rst GND1
C
D
10 nF
V
in
V
in
C
in
0.1
mF
C
out2
4.7
mF
Figure 1. Typical Application Circuit
漏
Semiconductor Components Industries, LLC, 2004
1
February, 2004 鈭?Rev. 4
Publication Order Number:
NCP4672/D

NCP4672DR2G 產品屬性

  • 2,500

  • 集成電路 (IC)

  • PMIC - 穩壓器 - 線性

  • -

  • 正，固定式

  • 3.5V，1.8V

  • 3.8 V ~ 16 V

  • 0.15V @ 20mA

  • 2

  • 20mA（最小值），70mA（最小值）

  • 30mA，80mA

  • -30°C ~ 85°C

  • 表面貼裝

  • 8-SOIC（0.154"，3.90mm 寬）

  • 8-SOICN

  • 帶卷 (TR)

  • NCP4672DR2GOS
