NCP4515SN1.8T1 Datasheet

  • NCP4515SN1.8T1

  • Analog IC

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP4515
100 mA CMOS LDO with
Shutdown and Reference
Bypass
The NCP4515 is a high accuracy (typically
"0.5%)
CMOS
upgrade for older (bipolar) low dropout regulators such as the LP2980.
Designed specifically for battery鈥搊perated systems, the devices鈥?/div>
CMOS construction eliminates wasted ground current, significantly
extending battery life. Total supply current is typically 50
碌A(chǔ)
at full
load (20 to 60 times lower than in bipolar regulators).
Key features for the devices include ultra low鈥搉oise operation (plus
optional Bypass input), fast response to step changes in load, and very
low dropout voltage, typically 180 mV at full load. Supply current is
reduced to 0.5
碌A(chǔ)
(max) and V
OUT
falls to zero when the shutdown
input is low. The devices also incorporate both over鈥搕emperature and
over鈥揷urrent protection.
The NCP4515 is stable with an output capacitor of only 1.0
碌F
and
has a maximum output current of 50 mA, 100 mA, and 150 mA,
respectively. For higher output versions, see the NCP4569
(I
OUT
= 300 mA) data sheet.
Features
http://onsemi.com
5
4
1
2
SOT鈥?3
SN SUFFIX
CASE 1212
3
PIN CONNECTIONS
V
IN
1
GND 2
SHDN 3
(Top View)
4 Bypass
5 V
OUT
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Extremely Low Supply Current (50
碌A(chǔ),
Typ.)
Very Low Dropout Voltage
Guaranteed 100 mA Output
High Output Voltage Accuracy
Standard or Custom Output Voltages
Power鈥揝aving Shutdown Mode
Reference Bypass Input for Ultra Low鈥揘oise Operation
Over鈥揅urrent and Over鈥揟emperature Protection
Space鈥揝aving 5鈥揚in SOT鈥?3A Package
Pin Compatible Upgrades for Bipolar Regulators
Battery鈥揙perated Systems
Portable Computers
Medical Instruments
Instrumentation
Cellular/GSM/PHS Phones
Linear Post鈥揜egulator for SMPS
Pagers
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 14 of this data sheet.
DEVICE MARKING INFORMATION
See general marking information in the device marking
section on page 14 of this data sheet.
Applications
漏
Semiconductor Components Industries, LLC, 2001
1
February, 2001 鈥?Rev. 0
Publication Order Number:
NCP4515/D
