NCP1800DM42R2 Datasheet

  • NCP1800DM42R2

  • Single-Cell Lithium Ion Battery Charge Controller

  • 14頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規(guī)格書

PDF預覽

NCP1800
Single鈭扖ell Lithium Ion
Battery Charge Controller
The NCP1800 is a constant current, constant voltage (CCCV)
lithium ion battery charge controller. The external sense resistor sets
the full charging current, and the termination current is 10% of the full
charge current (0.1 C). The voltage is regulated at
鹵1%
during the
final charge stage. There is virtually zero drain on the battery when the
input power is removed.
Features
http://onsemi.com
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Integrated Voltage and Programmable Current Regulation
Integrated Cell Conditioning for Deeply Discharged Cell
Integrated End of Charge Detection
Better than 1% Voltage Regulation
Charger Status Output for LED or Host Processor Interface
Charge Interrupt Input
Safety Shutoff for Removal of Battery
Adjustable Charge Current Limit
Input Over and Under Voltage Lockout
Micro8 Package
8
1
Micro8t
CASE 846A
DM SUFFIX
PIN CONNECTIONS AND
MARKING DIAGRAM
ISNS
ISEL
COMP/DIS
GND
1
180X
AYW
2
3
4
8
7
6
5
OUT
V
CC
CFLG
VSNS
Applications
鈥?/div>
Cellular Phones, PDAs
鈥?/div>
Handheld Equipment
鈥?/div>
Battery Operated Portable Devices
PMOS/Schottky (FETKYt): NTHD4P02FT1 (ChipFETt)
PMOS: NTGS3441T1 (TSOP 6)
Schottky: MBRM130L
R
SNS
V
in
X = A for 41 Device
B for 42 Device
A = Assembly Location
L = Wafer Lot
Y = Year
W = Work Week
ORDERING INFORMATION
Device
NCP1800DM41R2
NCP1800DM42R2
Package
Micro8
Micro8
Shipping
4000 Units/Reel
4000 Units/Reel
OUT
V
CC
ISNS
NCP1800
VSNS
Host or LED
Host
Processor
CFLG
COMP/
DIS
R
COMP
C
in
GND
ISEL
R
ISEL
60 k
C
out
C
COMP
R
COMP
= 15
W,
C
COMP
= 560 nF
Figure 1. Typical Application
漏
Semiconductor Components Industries, LLC, 2003
1
May, 2003 - Rev. 4
Publication Order Number:
NCP1800/D
