NCP1417 Datasheet

  • NCP1417

  • 200 mA DC-DC Step-up Converter with Dual Low Battery Protect...

  • 132.26KB

  • 16頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP1417
200 mA DC-DC Step-up
Converter with Dual Low
Battery Protection
NCP1417 is a monolithic micropower high frequency Boost
(step鈥搖p) voltage switching converter IC specially designed for
battery operated hand鈥揾eld electronic products up to 200 mA loading.
It integrates Synchronous Rectifier for improving efficiency as well as
eliminating the external Schottky Diode. High switching frequency
(up to 600 kHz) allows use of a low profile inductor and output
capacitor. Dual Low鈥揃attery Detectors and Cycle鈥揵y鈥揅ycle Current
Limit provide value鈥揳dded features for various battery鈥搊perated
applications. With all these functions ON, the quiescent supply current
is only 9.0
mA
typical. This device is available in a space saving
compact Micro8t package.
Features
http://onsemi.com
MARKING
DIAGRAM
8
8
1
Micro8
DM SUFFIX
CASE 846A
1
1417
A
Y
W
= Device Marking
= Assembly Location
= Year
= Work Week
1417
AYW
鈥?/div>
High Efficiency, Up to 92%, Typical
鈥?/div>
Very Low Device Quiescent Supply Current of 9.0
mA
Typical
鈥?/div>
Built鈥搃n Synchronous Rectifier (P鈥揊ET) Eliminates One External
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Schottky Diode
High Switching Frequency (Up to 600 kHz) Allows Small Size
Inductor and Capacitor
High Accuracy Reference Output, 1.19 V
鹵
0.6% @ 25_C, Can
Supply More Than 2.5 mA when V
OUT
鈮?/div>
3.3 V
1.0 V Startup at No Load Guaranteed
Output Voltage from 1.5 V to 5.5 V Adjustable
Output Current Up to 200 mA @ V
in
= 2.5 V, V
out
= 3.3 V
Multi鈥揊unction LBI/Shutdown Control Pin
Dual Open Drain Low鈥揃attery Detector Outputs
1.0 A Cycle by Cycle Current Limit
Low Profile and Minimum External Parts
Compact Micro8 Package
Personal Digital Assistants (PDA)
Handheld Digital Audio Product
Camcorders and Digital Still Camera
Handheld Instrument
Conversion from One or Two NiMH or NiCd or One Lithium鈥搃on
Cells to 3.3 V/5.0 V
PIN CONNECTIONS
FB
LBI/SHDN
LBO1
REF
1
2
3
4
(Top View)
8
7
6
5
OUT
LX
GND
LBO2
ORDERING INFORMATION
Device
NCP1417DMR2
Package
Micro8
Shipping
4000 Tape & Reel
Applications
漏
Semiconductor Components Industries, LLC, 2002
1
April, 2002 鈥?Rev. 1
Publication Order Number:
NCP1417/D
