NC7SV02P5X Datasheet

  • NC7SV02P5X

  • TinyLogic ULP-A 2-Input NOR Gate

  • 308.46KB

  • 9頁

  • FAIRCHILD

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NC7SV02 TinyLogic錚?ULP-A 2-Input NOR Gate
June 2002
Revised March 2003
NC7SV02
TinyLogic
錚?/div>
ULP-A 2-Input NOR Gate
General Description
The NC7SV02 is a single 2-Input NOR Gate from
Fairchild鈥檚 Ultra Low Power-A (ULP-A) Series of
TinyLogic
錚?/div>
. ULP-A is ideal for applications that require
extreme high speed, high drive and low power. This prod-
uct is designed for a wide low voltage operating range
(0.9V to 3.6V V
CC
) and applications that require more drive
and speed than the TinyLogic ULP series, but still offer
best in class low power operation.
The NC7SV02 is uniquely designed for optimized power
and speed, and is fabricated with an advanced CMOS
technology to achieve high-speed operation while main-
taining low CMOS power dissipation.
Features
s
0.9V to 3.6V V
CC
supply operation
s
3.6V overvoltage tolerant I/O鈥檚 at V
CC
from 0.9V to 3.6V
s
Extremely High Speed t
PD
1.0 ns typ for 2.7V to 3.6V V
CC
1.2 ns typ for 2.3V to 2.7V V
CC
1.9 ns typ for 1.65V to 1.95V V
CC
3.2 ns typ for 1.4V to 1.6V V
CC
6.0 ns typ for 1.1V to 1.3V V
CC
13 ns typ for 0.9V V
CC
s
Power-Off high impedance inputs and outputs
s
High Static Drive (I
OH
/I
OL
)
鹵
24 mA @ 3.00V V
CC
鹵
18 mA @ 2.30V V
CC
鹵
6 mA
鹵
4 mA
鹵
2 mA
@ 1.65V V
CC
@ 1.4V V
CC
@ 1.1V V
CC
鹵
0.1 mA @ 0.9V V
CC
s
Uses patented Quiet Series
錚?/div>
noise/EMI reduction
circuitry
s
Ultra small MicroPak
錚?/div>
leadfree package
s
Ultra low dynamic power
Ordering Code:
Order Number
NC7SV02P5X
NC7SV02L6X
Package
Number
MAA05A
MAC06A
Product Code
Top Mark
V02
F6
Package Description
5-Lead SC70, EIAJ SC-88a, 1.25mm Wide
6-Lead MicroPak, 1.0mm Wide
Supplied As
3k Units on Tape and Reel
5k Units on Tape and Reel
Battery Life vs. V
CC
Supply Voltage
TinyLogic ULP and ULP-A with up to 50% less power consumption can
extend your battery life significantly.
Battery Life
=
(V
battery
*I
battery
*.9)/(P
device
)/24hrs/day
Where, P
device
=
(I
CC
* V
CC
)
+
(C
PD
+
C
L
) * V
CC2
* f
Assumes ideal 3.6V Lithium Ion battery with current rating of 900mAH and
derated 90% and device frequency at 10MHz, with C
L
=
15 pF load
TinyLogic錚?is a registered trademark of Fairchild Semiconductor Corporation.
Quiet Series錚?is a trademark of Fairchild Semiconductor Corporation.
漏 2003 Fairchild Semiconductor Corporation
DS500602
www.fairchildsemi.com

NC7SV02P5X 產品屬性

  • 3,000

  • 集成電路 (IC)

  • 邏輯 - 柵極和逆變器

  • 7SV

  • 或非門

  • 1

  • 2

  • -

  • 0.9 V ~ 3.6 V

  • 0.9µA

  • 24mA，24mA

  • 0.7 V ~ 0.8 V

  • 1.6 V ~ 2 V

  • 3.3ns @ 2.7V ~ 3.6V，30pF

  • -40°C ~ 85°C

  • 表面貼裝

  • SC-70-5

  • 6-TSSOP（5 引線），SC-88A，SOT-353

  • 帶卷 (TR)

NC7SV02P5X相關型號PDF文件下載

  • 型號
    版本
    描述
    廠商
    下載
  • 英文版
    TinyLogic HS 2-Input NAND Gate
    FAIRCHILD
  • 英文版
    TinyLogic HS 2-Input NAND Gate
    FAIRCHILD ...
  • 英文版
    TinyLogic HS 2-Input NOR Gate
    FAIRCHILD
  • 英文版
    TinyLogic HS 2-Input NOR Gate
    FAIRCHILD ...
  • 英文版
    TinyLogic HS Inverter
    FAIRCHILD
  • 英文版
    TinyLogic HS Inverter
    FAIRCHILD ...
  • 英文版
    TinyLogic HS 2-Input AND Gate
    FAIRCHILD
  • 英文版
    TinyLogic HS 2-Input AND Gate
    FAIRCHILD ...
  • 英文版
    TinyLogic HS Inverter with Schmitt Trigger Input
    FAIRCHILD
  • 英文版
    TinyLogic HS Inverter with Schmitt Trigger Input
    FAIRCHILD ...
  • 英文版
    TinyLogic HS 2-Input OR Gate
    FAIRCHILD
  • 英文版
    TinyLogic HS 2-Input OR Gate
    FAIRCHILD ...
  • 英文版
    TinyLogic HS 2-Input Exclusive-OR Gate
    FAIRCHILD
  • 英文版
    TinyLogic HS 2-Input Exclusive-OR Gate
    FAIRCHILD ...
  • 英文版
    TinyLogic. ULP Universal Configurable 2-Input Logic Gates
    FAIRCHILD
  • 英文版
    TinyLogic. ULP Universal Configurable 2-Input Logic Gates
    FAIRCHILD ...
  • 英文版
    TinyLogic ULP 2-Input NAND Gate
    FAIRCHILD ...
  • 英文版
    TinyLogic ULP 2-Input NOR Gate
    FAIRCHILD
  • 英文版
    TinyLogic ULP 2-Input NOR Gate
    FAIRCHILD ...
  • 英文版
    TinyLogic ULP Inverter
    FAIRCHILD
