NBLVEP16VRMNR2 Datasheet

  • NBLVEP16VRMNR2

  • 2.5V/3.3V/5V ECL Differential Receiver/Driver with Oscillat...

  • 120.56KB

  • 14頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NBLVEP16VR
2.5V/3.3V/5V ECL
Differential Receiver/Driver
with Oscillator Gain Stage
and Enabled High Gain
Outputs
The NBLVEP16VR is an ECL/LVPECL oscillator gain stage with
high鈭抔ain output buffers, selectable output enable and a feedback
buffer. The NBLVEP16VR is a solution for crystal oscillators and
SAW鈭抌ased voltage鈭抍ontrolled oscillators.
鈥?/div>
Q and Q Outputs have Selectable 4 mA or 8 mA, Self Bias Current
Sources
鈥?/div>
QHG and QHG have a Selectable 10 mA, Self Bias Current Sources
鈥?/div>
Synchronous Output Enable of the High鈭扜ain Outputs with
Selectable Disabled State
鈥?/div>
Selectable LVCMOS/LVTTL or LVPECL Level Input of the Output
Enable Pin
鈥?/div>
Maximum Frequency > 2.5 GHz Typical
鈥?/div>
(LV)PECL Mode Operating Range: V
CC
= 2.375 V to 5.5 V with
V
EE
= 0 V
鈥?/div>
NECL Mode Operating Range: V
CC
= 0 V with
V
EE
= 鈭?.375 V to 鈭?.5 V
鈥?/div>
Temperature Compensated Inputs and Outputs
鈥?/div>
Excellent Clock Input Sensitivity
鈥?/div>
V
BB
Output Supports Current Source/Sink Capability up to a
Robust 1.5 mA
http://onsemi.com
MARKING DIAGRAM
Bottom View
QFN鈭?6
MN SUFFIX
CASE 485G
XXXX
A
L
Y
W
XXXX
XXXX
ALYW
= Device Code
= Assembly Location
= Wafer Lot
= Year
= Work Week
ORDERING INFORMATION
Device
NBLVEP16VRMN
NBLVEP16VRMNR2
Package
QFN鈭?6
QFN鈭?6
Shipping
鈥?/div>
123 / Rail
3000/ Tape &
Reel
Refer to
Note 1.
NBWLVEP16VR
Wafer
1. Contact Sales Representative.
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
4 mA ea. (opt.) Brochure, BRD8011/D.
4 mA ea.
CS_SEL
V
EE
Q
Q
D
D
470
W
V
BB
V
BB_ADJ
OD_MODE
LEN Q
LATCH
D
470
W
0
V
BB
Q
Q
1
QHG
QHG
10 mA ea. (opt.)
V
EEP
EN
LVCMOS/LVTTL
Threshold
EN_SEL
Figure 1. Logic Diagram
漏
Semiconductor Components Industries, LLC, 2003
1
December, 2003 鈭?Rev. 2
Publication Order Number:
NBLVEP16VR/D
