Package type:
-
-
-
-
-
32 pin plastic DIP
32 pin SOP
8x20mm 32-lead TSOP(I)
8x14mm 32-lead TSOP(I)
8x13.4mm 32-lead TSOP(I)
GENERAL DESCRIPTION
The MX27L2000 is a 3V only, 2M-bit, One Time
Programmable Read Only Memory. It is organized as
256K words by 8 bits per word, operates from a single +
3 volt supply, has a static standby mode, and features
fast single address location programming. All program-
ming signals are TTL levels, requiring a single pulse. For
programming outside from the system, existing EPROM
programmers may be used. The MX27L2000 supports
a intelligent fast programming algorithm which can result
in programming time of less than one minute.
This EPROM is packaged in industry standard 32 pin
dual-in-line packages, 32 lead SOP and 32 lead
TSOP(I) packages.
PIN CONFIGURATIONS
32 PDIP/SOP
VPP
A16
A15
A12
A7
A6
A5
A4
A3
A2
A1
A0
Q0
Q1
Q2
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
VCC
PGM
A17
A14
A13
A8
A9
A11
OE
A10
CE
Q7
Q6
Q5
Q4
Q3
BLOCK DIAGRAM
CE
PGM
OE
CONTROL
LOGIC
OUTPUT
BUFFERS
Q0~Q7
MX27L2000
.
.
.
A0~A17
ADDRESS
INPUTS
.
.
.
.
.
VCC
VSS
Y-DECODER
.
.
.
.
.
.
.
.
Y-SELECT
X-DECODER
2M BIT
CELL
MAXTRIX
32 TSOP(I) (8x20mm,8x14mm,8x13.4mm)
A11
A9
A8
A13
A14
A17
PGM
VCC
VPP
A16
A15
A12
A7
A6
A5
A4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
OE
A10
CE
Q7
Q6
Q5
Q4
Q3
GND
Q2
Q1
Q0
A0
A1
A2
A3
PIN DESCRIPTION
SYMBOL
A0~A17
Q0~Q7
CE
OE
PGM
VPP
NC
VCC
GND
PIN NAME
Address Input
Data Input/Output
Chip Enable Input
Output Enable Input
Programmable Enable Input
Program Supply Voltage
No Internal Connection
Power Supply Pin (+5V)
Ground Pin
REV. 2.8, AUG. 20,2001
MX27L2000
P/N: PM0372
1
