MX27C1000/1001
1M-BIT [128K x 8] CMOS EPROM
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
128K x 8 organization
Single +5V power supply
+12.5V programming voltage
Fast access time: 45/55/70/90/100/120/150 ns
Totally static operation
Completely TTL compatible
鈥?/div>
Operating current: 30mA
鈥?/div>
Standby current: 100uA
鈥?/div>
Package type:
-
-
-
-
32 pin plastic DIP
32 pin SOP
32 pin PLCC
32 pin TSOP
GENERAL DESCRIPTION
The MX27C1000/1001 is a 5V only, 1M-bit, ultraviolet
Erasable Programmable Read Only Memory. It is organ-
ized as 128K words by 8 bits per word, operates from a
single + 5 volt supply, has a static standby mode, and
features fast single address location programming. All
programming signals are TTL levels, requiring a single
pulse. For programming outside from the system,
existing EPROM programmers may be used. The
MX27C1000/1001 supports an intelligent fast
programming algorithm which can result in programming
time of less than thirty seconds.
This EPROM is packaged in industry standard 32 pin
dual-in-line packages, 32 lead PLCC , 32 lead SOP , and
32 lead TSOP packages.
PIN CONFIGURATIONS
PDIP/SOP
VPP
A16
A15
A12
A7
A6
A5
A4
A3
A2
A1
A0
Q0
Q1
Q2
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
VCC
PGM
NC
A14
A13
A8
A9
A11
OE
A10
CE
Q7
Q6
Q5
Q4
Q3
PDIP/SOP(MX27C1001)
VPP
OE
A15
A12
A7
A6
A5
A4
A3
A2
A1
A0
Q0
Q1
Q2
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
VCC
PGM
NC
A14
A13
A8
A9
A11
A16
A10
CE
Q7
Q6
Q5
Q4
Q3
MX27C1000
PGM
PLCC
VCC
VPP
A12
A15
A16
TSOP(MX27C1000)
NC
MX27C1001
A7
A6
A5
A4
A3
A2
A1
A0
Q0
5
4
1
32
30
29
A14
A13
A8
A9
9
MX27C1000
25
A11
OE
A10
CE
13
14
Q1
Q2
GND
17
Q3
Q4
Q5
21
20
Q6
Q7
A11
A9
A8
A13
A14
NC
PGM
VCC
VPP
A16
A15
A12
A7
A6
A5
A4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
MX27C1000
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
OE
A10
CE
Q7
Q6
Q5
Q4
Q3
GND
Q2
Q1
Q0
A0
A1
A2
A3
P/N: PM0234
This Material Copyrighted by Its Respective Manufacturer
1
REV. 5.5,FEB. 25, 2000
