MwT-0820S-4N2/0820Z-4N2
8.0-20.0 GHz Balanced Amplifier Module
www.mwtinc.com
Email: info@mwtinc.com
TYPICAL SPECIFICATIONS AT 25 C
14.0 dBm P-1dB
6.5 dB SMALL SIGNAL GAIN
15.0 dB RETURN LOSS
40 mA @ +8V
USES TWO MwT-4 GaAs FET DEVICES
5.0 dB NOISE FIGURE
7.0
Typical Small
Signal Gain (dB)
8.0
7.0
6.0
8
14
Frequency (GHz)
20
Typical Noise
Figure (dB)
6.0
5.0
4.0
3.0
8
14
Frequency (GHz)
20
ELECTRICAL SPECIFICATIONS
SYMBOL
FREQ
SSG
G/ F
G/ T
P-1dB
PSAT
P/ T
IP3
2nd HAR
2nd HAR
NF
VSWR IN
VSWR OUT
ISO
VDD
IDD
RTH
PARAMETERS
(Ta=25 C)
UNITS
GHz
dB
+/-dB
dB/ C
dBm
dBm
dB/ C
dBm
dBc
dBc
dB
-----
-----
dB
+V
mA
C/W
MIN
8.0
6.0
TYP
MAX
20.0
6.5
0.4
-.012
14.0
16.0
-.008
25.0
-21.0
-16.0
4.5
1.5:1
1.5:1
-20.0
8.0
40.0
216.0
0.6
Frequency Range
Small Signal Gain
SSG Flatness
SSG Variation over Temperature
Output Power at 1dB Compression
Output Power at 6 dB Compression
P-1dB Variation over Temperature
Third Order Intercept Point
2nd Harmonic at Pout=14.0 dBm
2nd Harmonic at Pout=16.0 dBm
Noise Figure
Input VSWR
Output VSWR
Reverse Isolation
Power Supply Voltage
Small Signal Module Current
Thermal Resistance Including FET*
11.0
5.5
1.7:1
1.7:1
8.1
60.0
7.9
* When calculating Tch, use FET Vds = 4.0 volts and FET ds = 20 mA
