MwT-0206S-11P2/0206Z-11P2
2.0-6.0 GHz Balanced Amplifier Module
www.mwtinc.com
Email: info@mwtinc.com
TYPICAL SPECIFICATIONS AT 25 C
30.0 dBm P-1dB
6.0 dB SMALL SIGNAL GAIN
+41 dBm IP3
850 mA @ +8V
USES TWO MwT-11 GaAs FET DEVICES
7.0 dB NOISE FIGURE
8
Typical Small
Signal Gain (dB)
7
6
5
2
3
4
5
Frequency (GHz)
6
0
5
10
15
20
S
11
2
3
4
5
Frequency (GHz)
6
S
22
ELECTRICAL SPECIFICATIONS
SYMBOL
FREQ
SSG
G/ F
G/ T
P-1dB
PSAT
P/ T
IP3
2nd HAR
2nd HAR
NF
VSWR IN
VSWR OUT
ISO
VDD
IDD
RTH
PARAMETERS
(Ta=25 C)
UNITS
GHz
dB
+/-dB
dB/ C
dBm
dBm
dB/ C
dBm
dBc
dBc
dB
-----
-----
dB
+V
mA
C/W
MIN
2.0
5.0
TYP
MAX
6.0
6.0
0.4
-.012
30.0
31.0
-.008
41.0
-21.0
-16.0
7.0
1.7:1
1.7:1
-18.0
8.0
850.0
41.0
0.6
Frequency Range
Small Signal Gain
SSG Flatness
SSG Variation over Temperature
Output Power at 1dB Compression
Output Power at 6 dB Compression
P-1dB Variation over Temperature
Third Order Intercept Point
2nd Harmonic at Pout=30.0 dBm
2nd Harmonic at Pout=31.0 dBm
Noise Figure
Input VSWR
Output VSWR
Reverse Isolation
Power Supply Voltage
Small Signal Module Current
Thermal Resistance Including FET*
Typical Input/Output
Return Loss (dB)
29.5
2.0:1
2.0:1
8.1
950.0
7.9
* When calculating Tch, use FET Vds = 6.0 volts and FET ds = 440mA
4268 Solar Way Fremont California 94538 Phone: (510) 651-6700 Fax: (510) 651-2208
651-2208
All rights reserved. MicroWave Technology, Inc. All specifications subject to change without notice.
