MwT-0206L-VRM/0206U-VRM
2.0-6.0 GHz Voltage Regulator Module
www.mwtinc.com
Email: info@mwtinc.com
TYPICAL SPECIFICATIONS AT 25 C
DUAL ADJUSTABLE VOLTAGE REGULATOR
INTEGRAL 50 OHM LINE FOR RF INTERCONNECTION
CURRENT CAPABILITY: UP TO 400mA PER CHIP
800mA MAX PER MODULE
BUILT-IN REVERSE VOLTAGE PROTECTION
BUILT-IN THERMAL SHUTDOWN
V IN
LM117
V OUT
R1
VO= 1.25 (1+R2/R1)
R2
VOLTAGE REGULATOR
CIRCUIT SCHEMATIC
ELECTRICAL SPECIFICATIONS
SYMBOL
FREQ
VIN
V OUT1
V OUT2
IDC
IR
RR
Pd
PARAMETERS
(Ta=25 C)
UNITS
GHz
+V
+V
+V
mA
mA
dB
Watts
MIN
0.5
10.7
7.9
7.9
TYP
MAX
6.0
20.0
8.1
8.1
800
20.0
Frequency Range
Power Supply Voltage
Regulated Output Voltage 1 (1)
Regulated Output Voltage 2 (2)
DC Current, total for two regulators
Residual Current
Ripple Rejection @ 120 Hz
Max. DC power dissipation @ each regulator
12.0
8.0
8.0
50.0
1.5
(1) The output voltage can be adjusted between 1.25 volts to Vin - 2.7 volts
