MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by MRF19060/D
The RF MOSFET Line
RF Power Field Effect Transistors
N鈥揅hannel Enhancement鈥揗ode Lateral MOSFETs
Designed for PCN and PCS base station applications with frequencies from
1.9 to 2.0 GHz. Suitable for CDMA, TDMA, GSM and multicarrier amplifier
applications.
鈥?/div>
Typical CDMA Performance: 1960 MHz, 26 Volts
IS鈥?7 CDMA Pilot, Sync, Paging, Traffic Codes 8 Through 13
Output Power 鈥?7.5 Watts
Power Gain 鈥?12.5 dB
Adjacent Channel Power 鈥?/div>
885 kHz: 鈥?7 dBc @ 30 kHz BW
1.25 MHz: 鈥?5 dBc @ 12.5 kHz BW
2.25 MHz: 鈥?5 dBc @ 1 MHz BW
鈥?/div>
Internally Matched, Controlled Q, for Ease of Use
鈥?/div>
High Gain, High Efficiency and High Linearity
鈥?/div>
Integrated ESD Protection
鈥?/div>
Designed for Maximum Gain and Insertion Phase Flatness
鈥?/div>
Capable of Handling 10:1 VSWR, @ 26 Vdc, 1.93 GHz, 60 Watts CW
Output Power
鈥?/div>
Excellent Thermal Stability
鈥?/div>
Characterized with Series Equivalent Large鈥揝ignal Impedance Parameters
鈥?/div>
Available in Tape and Reel. R3 Suffix = 250 Units per 56 mm, 13 Inch
Reel.
MRF19060
MRF19060R3
MRF19060SR3
1990 MHz, 60 W, 26 V
LATERAL N鈥揅HANNEL
RF POWER MOSFETs
CASE 465鈥?6, STYLE 1
NI鈥?80
MRF19060R3
CASE 465A鈥?6, STYLE 1
NI鈥?80S
MRF19060SR3
MAXIMUM RATINGS
Rating
Drain鈥揝ource Voltage
Gate鈥揝ource Voltage
Total Device Dissipation @ T
C
鈮?/div>
= 25擄C
Derate above 25擄C
Storage Temperature Range
Operating Junction Temperature
Symbol
V
DSS
V
GS
P
D
T
stg
T
J
Value
65
鈥?.5, +15
180
1.03
鈥?5 to +150
200
Unit
Vdc
Vdc
Watts
W/擄C
擄C
擄C
ESD PROTECTION CHARACTERISTICS
Test Conditions
Human Body Model
Machine Model
Class
1 (Minimum)
M3 (Minimum)
THERMAL CHARACTERISTICS
Characteristic
Thermal Resistance, Junction to Case
Symbol
R
胃JC
Max
0.97
Unit
擄C/W
NOTE 鈥?/div>
CAUTION
鈥?MOS devices are susceptible to damage from electrostatic charge. Reasonable precautions in handling and
packaging MOS devices should be observed.
REV 5
MOTOROLA RF
錚?/div>
Motorola, Inc. 2002
DEVICE DATA
MRF19060 MRF19060R3 MRF19060SR3
1
