Freescale Semiconductor, Inc.
MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order number: MPX5100/D
Rev 9, 3/2004
Integrated Silicon Pressure Sensor
On-Chip Signal Conditioned,
Temperature Compensated
and Calibrated
The MPX5100/MPXV5100 series piezoresistive transducer is a state-of-
the-art monolithic silicon pressure sensor designed for a wide range of appli-
cations, but particularly those employing a microcontroller or microprocessor
with A/D inputs. This patented, single element transducer combines advanced
micromachining techniques, thin-film metallization, and bipolar processing to
provide an accurate, high level analog output signal that is proportional to the
applied pressure.
MPX5100/MPXV5100
SERIES
INTEGRATED PRESSURE SENSOR
Differential
Absolute
0 to 100 kPa (0 to 14.5 psi)
15 to 115 kPa (2.18 to 16.68 psi)
0.2 to 4.7 Volts Output
SMALL OUTLINE
PACKAGE
UNIBODY PACKAGE
Freescale Semiconductor, Inc...
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
2.5% Maximum Error over 0擄 to 85擄C
Ideally suited for Microprocessor or Microcontroller-Based
Systems
Patented Silicon Shear Stress Strain Gauge
Available in Absolute, Differential and Gauge Configurations
Ideal for Automotive and Non-Automotive Applications
V
S
MPX5100D
CASE 867
MPXV5100GC6U
CASE 482A
MPX5100DP
CASE 867C
THIN FILM
TEMPERATURE
COMPENSATION
AND
GAIN STAGE #1
GAIN STAGE #2
AND
GROUND
REFERENCE
SHIFT CIRCUITRY
SENSING
ELEMENT
MPXV5100GC7U
V
out
CASE 482C
GND
PINS 1 AND 5 THROUGH 8 ARE NO CONNECTS
FOR SMALL OUTLINE PACKAGE
PINS 4, 5, AND 6 ARE NO CONNECTS FOR
UNIBODY PACKAGE
1
2
3
4
MPX5100GSX
CASE 867F
PIN NUMBER
N/C
V
S
GND
V
out
5
6
7
8
N/C
N/C
N/C
N/C
1
2
3
PIN NUMBER
V
out
GND
V
S
4
5
6
N/C
N/C
N/C
Figure 1. Fully Integrated Pressure Sensor Schematic
NOTE: Pins 1, 5, 6, 7, and
8 are internal device
connections. Do not
connect to external
circuitry or ground. Pin1 is
noted by the notch in the
lead.
NOTE: Pins 4, 5, and 6
are internal device
connections. Do not
connect to external
circuitry or ground. Pin1 is
noted by the notch in the
lead.
漏 Motorola, Inc. 2004
For More Information On This Product,
Go to: www.freescale.com
