MP02X175 Series

MP02X175 Series

Phase Control Dual SCR, SCR/Diode Modules

Replaces January 2000 version, DS4478-3.0

DS4478-5.0 August 2001

FEATURES

s

Dual Device Module

s

Electrically Isolated Package

s

Pressure Contact Construction

s

International Standard Footprint

s

Alumina (non-toxic) Isolation Medium

KEY PARAMETERS

V

DRM

I

TSM

I

T(AV)(per arm)

V

isol

1600V

6800A

175A

3000V

Code

Circuit

APPLICATIONS

s

Motor Control

s

Controlled Rectifier Bridges

s

Heater Control

s

AC Phase Control

HBN

Fig.1 Circuit diagrams

HBT

HBP

VOLTAGE RATINGS

Type

Number

Repetitive

Peak

Voltages

V

DRM

V

RRM

1600

1400

1200

1000

Conditions

MP02X175-16

MP02X175-14

MP02X175-12

MP02X175-10

T

vj

= 125

o

C

I

DRM

= I

RRM

= 30mA

V

DSM

& V

RSM

=

V

DRM

& V

RRM

+ 100V

respectively

1

2

3

Lower voltage grades available.

ORDERING INFORMATION

Order As:

MP02HBT175-16

or

MP02HBT175-14

or

MP02HBT175-12

or

MP02HBT175-10

MP02HBP175-16

or

MP02HBP175-14

or

MP02HBP175-12

or

MP02HBP175-10

MP02HBN175-16

or

MP02HBN175-14

or

MP02HBN175-12

or

MP02HBN175-10

Note: When ordering, please use the complete part number.

Module type code: MP02.

For further information see Package Details.

Fig. 2 Electrical connections - (not to scale)

1/8

www.dynexsemi.com
