MN101C47C, MN101C47D
Type
ROM (脳8-bit)
脳
RAM (脳 8-bit)
脳
Package
(Conventional Package)
Minimum Instruction
Execution Time
Interrupts
Timer Counter
Serial Interface
Caption
I/O Pins
A/D Inputs
PWM
Special Ports
CRTC
Notes
I/O
MN101C47C
48 K
1.5 K
MN101C47D
64 K
2K
SDIP042-P-0600C
*Lead-free
, LQFP064-P-1414
*Lead-free
(SDIP042-P-0600)
279 ns (at 3.0 V to 3.6 V, 14.32 MHz)
External (6 lines)
Internal (8 lines) : Timer
脳
3, A/D, OSD, I
2
C, Remote control, Watchdog
8-bit timer
脳
3
Watchdog timer: system clock fs 1/2
16
, 1/2
18
, 1/2
20
triple selection
I
2
C
脳
1: for multimaster mode, bus line (output) has 2 systems
鈥?Built-in sync separator
脳
2
35
鈥?Common use: 29
5-bit
脳
8-ch. (with S/H)
8-bit
脳
6-ch. , 14-bit
脳
1-ch.
Remote control reception
1-layer display (graphics, characters)
Remote control input discriminant circuit built-in
Support Tool
In-circuit Emulator
EPROM Built-in Type
PX-ICE101C/D+PX-PRB101C47-SDIP046-P-0600-M (under development)
Type
ROM (脳 8-bit)
RAM (脳 8-bit)
Minimum instruction execution time
Package
(Conventional Package)
MN101CF46F (under development)
96 K
3K
279 ns (at 3.0 V to 3.6 V, 14.32 MHz)
SDIP042-P-0600C
*Lead-free
, LQFP064-P-1414
*Lead-free
(SDIP042-P-0600)
1
