M29W040B

4 Mbit (512Kb x8, Uniform Block)

Low Voltage Single Supply Flash Memory

s

SINGLE 2.7 to 3.6V SUPPLY VOLTAGE for

PROGRAM, ERASE and READ OPERATIONS

ACCESS TIME: 55ns

PROGRAMMING TIME

鈥?10碌s per Byte typical

8 UNIFORM 64 Kbytes MEMORY BLOCKS

PROGRAM/ERASE CONTROLLER

鈥?Embedded Byte Program algorithm

鈥?Embedded Multi-Block/Chip Erase algorithm

鈥?Status Register Polling and Toggle Bits

PLCC32 (K)

TSOP32 (N)

8 x 20mm

s

s

s

s

s

ERASE SUSPEND and RESUME MODES

鈥?Read and Program another Block during

Erase Suspend

TSOP32 (NZ)

8 x 14mm

s

UNLOCK BYPASS PROGRAM COMMAND

鈥?Faster Production/Batch Programming

LOW POWER CONSUMPTION

鈥?Standby and Automatic Standby

s

Figure 1. Logic Diagram

s

100,000 PROGRAM/ERASE CYCLES per

BLOCK

20 YEARS DATA RETENTION

鈥?Defectivity below 1 ppm/year

VCC

s

s

ELECTRONIC SIGNATURE

鈥?Manufacturer Code: 20h

鈥?Device Code: E3h

A0-A18

19

8

DQ0-DQ7

W

E

G

M29W040B

VSS

AI02953

April 2002

1/20
