LTC1272-3CCN Datasheet

  • LTC1272-3CCN

  • 12-Bit, 3us, 250kHz Sampling A/D Converter

  • 339.70KB

  • 20頁

  • LINER

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LTC1272
12-Bit, 3碌s, 250kHz
Sampling A/D Converter
FEATURES
s
s
s
s
s
s
s
s
s
s
s
DESCRIPTIO
AD7572 Pinout
12-Bit Resolution
3碌s and 8碌s Conversion Times
On-Chip Sample-and-Hold
Up to 250kHz Sample Rates
5V Single Supply Operation
No Negative Supply Required
On-Chip 25ppm/擄C Reference
75mW (Typ) Power Consumption
24-Pin Narrow DIP and SOL Packages
ESD Protected on All Pins
The LTC1272 is a 3碌s, 12-bit, successive approximation
sampling A/D converter. It has the same pinout as the
industry standard AD7572 and offers faster conversion
time, on-chip sample-and-hold, and single supply opera-
tion. It uses LTBiCMOS
TM
switched-capacitor technology to
combine a high speed 12-bit ADC with a fast, accurate
sample-and-hold and a precision reference.
The LTC1272 operates with a single 5V supply but can also
accept the 5V/鈥?5V supplies required by the AD7572 (Pin
23, the negative supply pin of the AD7572, is not connected
on the LTC1272). The LTC1272 has the same 0V to 5V input
range as the AD7572 but, to achieve single supply opera-
tion, it provides a 2.42V reference output instead of the
鈥?5.25V of the AD7572. It plugs in for the AD7572 if the
reference capacitor polarity is reversed and a 1碌s sample-
and-hold acquisition time is allowed between conversions.
The output data can be read as a 12-bit word or as two
8-bit bytes. This allows easy interface to both 8-bit and
higher processors. The LTC1272 can be used with a
crystal or an external clock and comes in speed grades of
3碌s and 8碌s.
LTBiCMOS is a trademark of Linear Technology Corporation
APPLICATI
s
s
s
s
S
High Speed Data Acquisition
Digital Signal Processing (DSP)
Multiplexed Data Acquisition Systems
Single Supply Systems
TYPICAL APPLICATI
2.42V
V
REF
OUTPUT
ANALOG INPUT
(0V TO 5V)
A
IN
V
REF
10碌F
AGND
Single 5V Supply, 3碌s, 12-Bit Sampling ADC
LTC1272
V
DD
NC
BUSY
CS
RD
HBEN
CLK OUT
CLK IN
D0/8
D1/9
D2/10
D3/11
鈥?20
鈥?40
0
1024 Point FFT, f
S
= 250kHz, f
IN
= 10kHz
5V
0
+
0.1碌F
10
碌
F
+
鈥?0
0.1
碌
F
鈥?0
AMPLITUDE (dB)
D11 (MSB)
D10
D9
D8
D7
8 OR 12-BIT
PARALLEL
BUS
D6
D5
D4
DGND
碌
P
CONTROL
LINES
鈥?0
鈥?0
鈥?00
20
LTC1272 鈥?TA01
U
S = 72.1
(N+D)
40
60
80
100
120
LTC1272 鈥?TA02
UO
UO
FREQUENCY (kHz)
1

LTC1272-3CCN 產品屬性

  • LTC1272

  • 15

  • 集成電路 (IC)

  • 數據采集 - 模數轉換器

  • -

  • 12

  • 250k

  • 并聯

  • 1

  • 75mW

  • 單電源

  • 0°C ~ 70°C

  • 通孔

  • 24-DIP（0.300"，7.62mm）

  • 24-PDIP

  • 管件

  • 1 個單端，單極
