Order this document by LT1585A/D
5A Low Dropout Fast Response
Positive Adjustable and Fixed
Voltage Regulators
The LT1585A is a low dropout 3鈥搕erminal voltage regulator with 5A output
current capability.
Design has been optimized for low voltage applications where transient
response and minimum input voltage are critical. This voltage regulator
features a low dropout voltage and fast transient response. These
improvements make them ideal for low voltage microprocessor applications
requiring a regulated 2.5V to 3.6V output with an input supply below 7V.
Current limits is trimmed to ensure specified output current and controlled
short鈥揷ircuit current. On鈥揷hip thermal limiting provides protection against
any combination of overload that would create excessive junction
temperatures. The LT1585A is available in the industry standard 3鈥損in
TO鈥?20 and D2PAK power package.
Features
鈥?/div>
Fast Transient Response
LT1585A
5A LOW DROPOUT FAST
RESPONSE POSITIVE
ADJUSTABLE AND FIXED
VOLTAGE REGULATOR
SILICON MONOLITHIC
INTEGRATED CIRCUIT
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Guaranteed Dropout Voltage at Multiple Currents
Load Regulation: 0.05% Typ
Trimmed Current Limit
On鈥揅hip Thermal Limiting
Standard 3鈥揚in Power Package
T SUFFIX
PLASTIC PACKAGE
CASE 221A
Adjustable output:
Pin 1. Adjust
Pin
2. Vout
Pin
3. Vin
Fixed 1.5V output:
Pin 1. Gnd
Pin
2. Vout
Pin
3. Vin
1
2
3
Applications
鈥?/div>
Pentium
廬
Processor Supplies
Power PC鈩?Supplies
Other 2.5V to 3.6V Microprocessor Supplies
Low Voltage Logic Supplies
Battery鈥揚owered Circuitry
Post Regulator for Switching Supply
1
Vin
Simplified Block Diagram
2
3
+
鈥?/div>
CM SUFFIX
PLASTIC PACKAGE
CASE 936
(D2PAK)
ORDERING INFORMATION
Device
Tested
Operating
Temp.
Range
0 to 125擄C
0 to 125擄C
Output
Voltage
Type
ADJ.
ADJ.
FIXED
1.5V
FIXED
1.5V
Package
Thermal
Limit
Vout
Adjust
LT1585ACT
LT1585ACM
TO鈥?20
D2PAK
TO鈥?20
D2PAK
Rev 0
LT1585ACT鈥?.5 0 to 125擄C
LT1585ACM鈥?.5 0 to 125擄C
漏
Motorola, Inc. 1999
MOTOROLA ANALOG IC DEVICE DATA
1
LT1585ACT-1.5 產(chǎn)品屬性
More Information on LDOs
50
集成電路 (IC)
PMIC - 穩(wěn)壓器 - 線性
-
正，固定式
1.5V
最高 7V
1.2V @ 5A
1
-
0°C ~ 125°C
通孔
TO-220-3
TO-220-3
管件
