LT1395/LT1396/LT1397

Single/Dual/Quad 400MHz

Current Feedback Amplifier

FEATURES

s

DESCRIPTIO

400MHz Bandwidth on

鹵

5V (A

V

= 1)

350MHz Bandwidth on

鹵

5V (A

V

= 2, 鈥?)

0.1dB Gain Flatness: 100MHz (A

V

= 1, 2 and 鈥?)

High Slew Rate: 800V/碌s

Wide Supply Range:

鹵2V(4V)

to

鹵6V(12V)

80mA Output Current

Low Supply Current: 4.6mA/Amplifier

LT1395: SO-8, SOT23-5 and SOT23-6 Packages

LT1396: SO-8 and MSOP Packages

LT1397: SO-14 and SSOP-16 Packages

The LT

廬

1395/LT1396/LT1397 are single/dual/quad

400MHz current feedback amplifiers with an 800V/碌s slew

rate and the ability to drive up to 80mA of output current.

The LT1395/LT1396/LT1397 operate on all supplies from

a single 4V to

鹵6V.

At

鹵5V,

they draw 4.6mA of supply

current per amplifier. The LT1395CS6 also adds a shut-

down pin. When disabled, the LT1395CS6 draws virtually

zero supply current and its output becomes high imped-

ance. The LT1395CS6 will turn on in only 30ns and turn off

in 40ns, making it ideal in spread spectrum and portable

equipment applications.

The LT1395/LT1396/LT1397 are manufactured on Linear

Technology鈥檚 proprietary complementary bipolar process.

They have standard single/dual/quad pinouts and they are

optimized for use on supply voltages of

鹵5V.

, LTC and LT are registered trademarks of Linear Technology Corporation.

APPLICATIO S

s

Cable Drivers

Video Amplifiers

MUX Amplifiers

High Speed Portable Equipment

IF Amplifiers

TYPICAL APPLICATIO

R

G1

1.02k

R

F1

255鈩?/div>

Unity-Gain Video Loop-Through Amplifier

R

G2

63.4鈩?/div>

R

F2

255鈩?/div>

10

0

鈥?/div>

3.01k

V

IN 鈥?/div>

1/2

LT1396

鈥?/div>

3.01k V

IN+

1/2

LT1396

鈥?0

GAIN (dB)

V

OUT

鈥?0

COMMON MODE SIGNAL

鈥?0

100

+

0.67pF

+

1% RESISTORS

FOR A GAIN OF G:

V

OUT

= G (V

IN+

鈥?V

IN 鈥?/div>

)

R

F1

= R

F2

R

G1

= (5G 鈥?1) R

F2

R

F2

R

G2

=

(5G 鈥?1)

TRIM CMRR WITH R

G1

1395/6/7 TA01

0.67pF

12.1k

BNC INPUTS

HIGH INPUT RESISTANCE DOES NOT LOAD CABLE

EVEN WHEN POWER IS OFF

U

Loop-Through Amplifier

Frequency Response

NORMAL SIGNAL

1k

10k 100k

1M

10M 100M 1G

1395/6/7 TA02

U

FREQUENCY (Hz)

1

數據列表
LT1395-97
標準包裝
100
類別
集成電路 (IC)
家庭
Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
系列
-
放大器類型
電流反饋
電路數
4
輸出類型
-
轉換速率
800 V/µs
增益帶寬積
-
-3db帶寬
400MHz
電流 - 輸入偏壓
10µA
電壓 - 輸入偏移
1000µV
電流 - 電源
4.6mA
電流 - 輸出 / 通道
80mA
電壓 - 電源，單路/雙路(±)
4 V ~ 12 V，±2 V ~ 6 V
工作溫度
0°C ~ 70°C
安裝類型
表面貼裝
封裝/外殼
16-SSOP（0.154"，3.90mm 寬）
供應商設備封裝
16-SSOP
包裝
管件
