SmartLED

廬

0603

Hyper-Bright LED

Lead (Pb) Free Product - RoHS Compliant

LS L296, LA L296, LO L296, LY L296

Vorl盲ufige Daten / Preliminary Data

Besondere Merkmale

鈥?/div>

Geh盲usetyp:

SMT Geh盲use 0603, farbloser

diffuser Verguss

鈥?/div>

Besonderheit des Bauteils:

kleinste Bauform

1,7 mm x 0,8 mm x 0,65 mm (LxBxH)

鈥?/div>

Wellenl盲nge:

633 nm (super-rot),

615 nm (amber), 606 nm (orange),

587 nm (gelb)

鈥?/div>

Abstrahlwinkel:

extrem breite

Abstrahlcharakteristik (160擄)

鈥?/div>

Technologie:

InGaAlP

鈥?/div>

optischer Wirkungsgrad:

7 lm/W (super-rot),

11 lm/W (amber, orange, gelb)

鈥?/div>

Gruppierungsparameter:

Lichtst盲rke,

Wellenl盲nge

鈥?/div>

Verarbeitungsmethode:

f眉r alle

SMT-Best眉cktechniken geeignet

鈥?/div>

L枚tmethode:

IR Reflow L枚ten und

Wellenl枚ten (TTW)

鈥?/div>

Vorbehandlung:

nach JEDEC Level 2

鈥?/div>

Gurtung:

8-mm Gurt mit 5000/Rolle, 酶180 mm

鈥?/div>

ESD-Festigkeit:

ESD-sicher bis 2 kV nach

JESD22-A114-D

Anwendungen

鈥?Informationsanzeigen im Au脽enbereich

鈥?Flache Hinterleuchtung (LCD, Mobile Phone,

Schalter, Display)

鈥?Signal- und Symbolleuchten

鈥?Markierungsbeleuchtung (z.B. Stufen,

Fluchtwege, u.盲.)

Features

鈥?/div>

package:

SMT package 0603, colorless

diffused resin

鈥?/div>

feature of the device:

smallest package

1.7 mm x 0.8 mm x 0.65 mm (LxWxH)

鈥?/div>

wavelength:

633 nm (super-red),

615 nm (amber), 606 nm (orange),

587 nm (yellow)

鈥?/div>

viewing angle:

extremely wide (160擄)

鈥?/div>

technology:

InGaAlP

鈥?/div>

optical efficiency:

7 lm/W (super-red),

11 lm/W (amber, orange, yellow)

鈥?/div>

grouping parameter:

luminous intensity,

wavelength

鈥?/div>

assembly methods:

suitable for all

SMT assembly methods

鈥?/div>

soldering methods:

IR reflow soldering and

TTW soldering

鈥?/div>

preconditioning:

acc. to JEDEC Level 2

鈥?/div>

taping:

8 mm tape with 5000/reel, 酶180 mm

鈥?/div>

ESD-withstand voltage:

up to 2 kV acc. to

JESD22-A114-D

Applications

鈥?outdoor displays

鈥?flat backlighting (LCD, cellular phones,

switches, displays)

鈥?signal and symbol luminaire

鈥?marker lights (e.g. steps, exit ways, etc.)
