Medical safety approvals
Universal input
3鈥?x 5鈥?footprint
Remote sense
Built-in EMI filter
Low output ripple
Adjustable output
Overvoltage protection
Overload protection
110 KHz switching frequency
LPX60 enclosure kit available
Safety ground leakage
current
Output
Maximum power
Adjustment range
Hold-up time
Overload protection
Overvoltage protection
Remote sense
60 W for convection;
80 W with 30 CFM forced air
-5, +10% minimum
20 ms @ 60 W load, 115 VAC nominal line
Short circuit protection on all outputs.
Case overload
protected @ 110-145%
above peak rating
5 V output: 5.7-6.7 VDC. Other outputs
10% to 25% above nominal output
Compensates for 0.5 V lead drop min. Will
operate without remote sense connected.
Reverse connection protected.
Environmental
Operating temperature: 0擄 to 50擄C ambient
derate each output at 2.5% per degree from 50擄 to
70擄C
Electromagnetic susceptibility: designed to meet
IEC 801, -2, -3, -4, -5, -6, Level 3
Humidity: Operating; non-condensing
5% to 95%
Vibration: Three orthogonal axes, sweep at 1
oct/min, 5 min. dwell at four major resonances
0.75 G peak 5 Hz to 500 Hz, operational
Storage temperature: -40擄 to 85擄C
Temperature coefficient: 鹵.04% per 擄C
MTBF demonstrated: >550,000 hours at full load
and 25擄C ambient conditions
Safety
VDE
UL
CSA
CE
0750/EN60601-1 (IEC601)
UL2601
CSA 22.2 No. 601.1
Mark (LVD)
21310-3336-0015
E182560
LR109492
rev 08.11.04
94
