Carton Quantity and Weight
Ampere
Ratings
0鈥?0
35鈥?0
*Weight per carton.
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000 VAC, 75-1500 VDC). Refer to BIF document #8002 or contact
Bussmann Application Engineering at 636-527-1270 for more information.
Carton
Qty.
10
10
Weight*
Lbs.
1.6
2.6
Kg.
0.725
1.178
A
10,000
100,000
RMS SYMMETRICAL CURRENTS IN AMPERES
A鈥揃=ASYMMETRICAL AVAILABLE PEAK
(2.3 x SYMM RMS AMPS)
12-1-99
A99074
Rev. A
Form No. LPS-RK 0-60
Page 1 of 2
BIF Doc #1001
200,000
1,000
1,000
AMPERE
RATING
Catalog Symbol and Amperes
INSTANTANEOUS PEAK LET-THROUGH CURRENT IN AMPS
Catalog Symbol:
LPS-RK_SP
Dual-Element, Time-Delay 鈥?10 seconds (minimum) at 500%
rated current
Current-Limiting
Ampere Rating:
鈦勨劍隆潞
to 60 Amperes
Voltage Rating:
600 Volts AC (or less)
Interrupting Rating:
AC: 300,000A RMS Sym.
DC: 50,000 Amperes
Agency Approvals:
UL Listed, Special Purpose**, Guide JFHR, File E56412
CSA Certified, (200,000AIR), Class RK1 per CSA C22.2,
No. 248.12, Class 1422-02, File 53787
Features:
鈥?Current-limitation for maximum short-circuit protection.
鈥?Type 2 protection for IEC and NEMA starters when
properly sized.
鈥?High inrush current motor protection.
鈥?Time-delay permits 130% FLA sizing for back-up motor
protection.
鈥?Protection against single-phase motor damage.
鈥?Low watt loss power consumption.
鈥?Electrically isolated end caps.
鈥?300 Vdc, U.L. Listed.
Applications:
鈥?Branch distribution
鈥?Motors
鈥?Transformers
鈥?Solenoids
鈥?General purpose circuits
Current-Limitation Curve
400,000
B
1
2
