LMC6772 Dual Micropower Rail-To-Rail Input CMOS Comparator with Open Drain Output
September 1995
LMC6772
Dual Micropower Rail-To-Rail Input CMOS Comparator
with Open Drain Output
General Description
The LMC6772 is an ultra low power dual comparator with a
maximum 10 碌A(chǔ)/comparator power supply current. It is de-
signed to operate over a wide range of supply voltages, with
a minimum supply voltage of 2.7V.
The common mode voltage range of the LMC6772 exceeds
both the positive and negative supply rails, a significant ad-
vantage in single supply applications. The open drain output
of the LMC6772 allows for wired-OR configurations. The
open drain output also offers the advantage of allowing the
output to be pulled to any voltage rail up to 15V, regardless
of the supply voltage of the LMC6772.
The LMC6772 is targeted for systems where low power con-
sumption is the critical parameter. Guaranteed operation at
supply voltages of 2.7V and rail-to-rail performance makes
this comparator ideal for battery-powered applications.
Refer to the LMC6762 datasheet for a push-pull output stage
version of this device.
Features
(Typical unless otherwise noted)
n
Low power consumption (max): I
S
= 10 碌A(chǔ)/comp
n
Wide range of supply voltages: 2.7V to 15V
n
Rail-to-Rail Input Common Mode Voltage Range
n
Open drain output
n
Short circuit protection: 40 mA
n
Propagation delay (
@
V
S
= 5V, 100 mV overdrive): 5 碌s
Applications
n
n
n
n
n
n
n
Laptop computers
Mobile phones
Metering systems
Hand-held electronics
RC timers
Alarm and monitoring circuits
Window comparators, multivibrators
Connection Diagram
8-Pin DIP/SO
DS012347-1
Top View
Ordering Information
Package
8-Pin Molded DIP
8-Pin Small Outline
Temperature Range
鈭?0藲C to +85藲C
LMC6772AIN, LMC6772BIN
LMC6772AIM, LMC6772BIM
LMC6772AIMX, LMC6772BIMX
N08E
M08A
M08A
NSC Drawing
Transport
Media
Rails
Rails
Tape and Reel
漏 1999 National Semiconductor Corporation
DS012347
www.national.com

LMC6772BIN 產品屬性

  • National Semiconductor (TI)

  • 2 Channels

  • Analog Comparators

  • Open Drain

  • 15 mV at 5 V

  • 0.02 mA at 5 V

  • + 85 C

  • Through Hole

  • MDIP

  • Tube

  • - 40 C

  • 40

  • 15 V

  • 2.7 V
