Ordering number : EN4929A
CMOS LSI
LC75366, 75366M
Two-Channel Electronic Volume Control
Overview
The LC75366 (DIP20) and the LC75366M (MFP20) are
electronic volume controls that can be controlled by serial
input data and provide volume, balance and loudness
functions.
Package Dimensions
unit: mm
3021B-DIP20
[LC75366]
Features
鈥?Silicon gate CMOS process for low switching noise
Functions
鈥?Volume: 0 dB to 鈥?8 dB (in 2 dB steps) and 鈥撯垶;
36 positions.
A balance function can be implemented by controlling
the left and right channel volume settings independently.
鈥?Loudness: Taps are provided at the 鈥?0 dB positions in
the 10 dB step resistor ladder used by the volume
control function. A loudness function can be
implemented by attaching external RC circuits at these
tap points.
鈥?An address selection pin (the S pin) allows two
LC75366 chips to be used on the same bus.
鈥?Serial data input: Supports CCB* format communication
with the system controller.
SANYO: DIP20
unit: mm
3036B-MFP20
[LC75366M]
鈥?CCB is a trademark of SANYO ELECTRIC CO., LTD.
鈥?CCB is SANYO鈥檚 original bus format and all the bus
addresses are controlled by SANYO.
Specifications
Absolute Maximum Ratings
at Ta = 25擄C, V
SS
= 0 V
Parameter
Maximum supply voltage
Maximum input voltage
Allowable power dissipation
Operating temperature
Storage temperature
Symbol
V
DD
max
V
IN
max1
V
IN
max2
Pd max
Topr
Tstg
V
DD
CL, DI, CE, S
L10dBIN, L2dBIN, R10dBIN, R2dBIN
Ta
鈮?/div>
85擄C
Conditions
SANYO: MFP20
Ratings
12
V
SS
鈥?0.3 to V
DD
+ 0.3
V
SS
鈥?0.3 to V
DD
+ 0.3
140
鈥?0 to +85
鈥?0 to +125
Unit
V
V
V
mW
擄C
擄C
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN
63096HA (OT)/62095HA (OT) No. 4929-1/11
