TO 8 WATTS
Wide input voltage range
Regulated outputs
Continuous short-circuit protection
1600VDC I/O Isolation
Metallic case for five-sided shielding
No derating to 70擄C
The LANCW series of dc/dc converters offers up to
8 watts of output power. The LANCW series is
intended to provide power and isolation for appli-
cations requiring high power density.
MODELS
MODEL
LANC123.3W8
LANC1205W8
LANC1212W8
LANC1215W8
LANC1205DW8
LANC1212DW8
LANC1215DW8
LANC243.3W8
LANC2405W8
LANC2412W8
LANC2415W8
LANC2405DW8
LANC2412DW8
LANC2415DW8
LANC483.3W8
LANC4805W8
LANC4812W8
LANC4815W8
LANC4805DW8
LANC4812DW8
LANC4815DW8
OUTPUT VDC OUTPUT CURRENT
3.3
2000
5
1500
12
666
15
533
+/-5
+/-800
+/-12
+/-333
+/-15
+/-267
18-36
3.3
2000
5
1500
12
666
15
533
+/-5
+/-800
+/-12
+/-333
+/-15
+/-267
36-75
3.3
2000
5
1500
12
666
15
533
+/-5
+/-800
+/-12
+/-333
+/-15
+/-267
For negative logic remote on/off, add suffix "R"
INPUT VDC
9-18
EFF.
80%
82%
83%
83%
83%
84%
84%
81%
82%
83%
83%
83%
84%
84%
81%
83%
84%
84%
83%
85%
85%
PIN CONNECTIONS
1
on/off
on/off
2,3
-V in
-V in
9
NC
Common
10
No Pin
No Pin
11
NC
-V out
14
+V out +V out
15
No Pin No Pin
16
-V out Common
22,23 +V in
+V in
603 778 2300
www.wallindustries.com
11/16/2002
1
