LAN91C96

ISA/PCMCIA Single-Chip Full Duplex Ethernet

Controller with Magic Packet

FEATURES

!"

ISA/PCMCIA Single-Chip Ethernet

Controller

!"

A Subset of Motorola 68000 Bus Interface

Support

!"

Fully Supports Full Duplex Switched

Ethernet

!"

Supports Enhanced Transmit Queue

Management

!"

6K Bytes of On-Chip RAM

!"

Supports IEEE 802.3 (ANSI 8802-3)

Ethernet Standards

!"

Automatic Detection of TX/RX Polarity

Reversal

!"

Enhanced Power Management Features

!"

Supports 鈥淢agic Packet鈥?Power

Management Technology

!"

Simultasking Early Transmit and Early

Receive Functions

!"

Enhanced Early Transmit Function

!"

Receive Counter for Enhanced Early

Receive

!"

Hardware Memory Management Unit

!"

Optional Configuration via Serial EEPROM

Interface (Jumperless)

!"

Supports single +5V or +3.3V (for Revisions

E and Later) VCC Designs

!"

Supports Mixed Voltage External PHY

1

Designs

!"

Low Power CMOS Design

!"

100 Pin QFP and TQFP (1.0 mm body

Thickness) Packages

!"

Pin Compatible with the LAN91C92 and

LAN91C94

1

Refer to

DESCRIPTION OF PIN

FUNCTIONS

on Page 13 for 5V tolerant pins

Bus Interface

!"

Direct Interface to ISA, PCMCIA, and 68000

Buses with No Wait States

!"

Flexible Bus Interface

!"

16 Bit Data and Control Paths

!"

Fast Access Time (40ns)

!"

Pipelined Data Path

!"

Handles Block Word Transfers for any

Alignment

!"

High Performance Chained ("Back-to-Back")

Transmit and Receive

!"

Pin Compatible with the LAN91C92 (in ISA

Mode) and the LAN91C94 in Both ISA and

PCMCIA Modes

!"

Dynamic Memory Allocation Between

Transmit and Receive

!"

Flat Memory Structure for Low CPU

Overhead

!"

Buffered Architecture, Insensitive to Bus

Latencies (No Overruns/Underruns)

!"

Supports Boot PROM for Diskless ISA

Applications

Network Interface

!"

Integrated 10BASE-T Transceiver

Functions:

-

Driver and Receiver

-

Link Integrity Test

-

Receive Polarity Detection and

Correction

!"

Integrated AUI Interface

!"

10 Mb/s Manchester Encoding/Decoding

and Clock Recovery

!"

Automatic Retransmission, Bad Packet

Rejection, and Transmit Padding

!"

External and Internal Loopback Modes

!"

Four Direct Driven LEDs for Status/

Diagnostics
