LA7285M Datasheet

  • LA7285M

  • VCR Audio Signal Recording and Playback Processor

  • 113.78KB

  • 7頁

  • SANYO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Ordering number:EN4091
Monolithic Linear IC
LA7285, 7285M
VCR Audio Signal Recording
and Playback Processor
Overview
The LA7285 and LA7285M include on chip all functions
required for the record and playback of VCR audio
signals. In addition, the inclusion of a switching circuit
for switching between tuner and line input in addition to
the circuits provided by earlier ICs makes the LA7285
truly optimal for audio VCR products.
Package Dimensions
unit:mm
3067-DIP24S
[LA7285]
Funtions
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Equalizer amplifier
Line amplifier
Recording/playback switch
Recording amplifier
Mute
SP, LP, EP switch
Ripple filter
ALC
Tape head switch
Line/tuner input switch
SANYO:DIP24S
unit:mm
3112-MFP24S
[LA7285M]
Features
鈥?Built-in input switching circuit (for the line and tuner
inputs).
鈥?Smaller package leaves large space for other
components.
鈥?Equalizer input/output capacitors not required.
鈥?Low gain variation eliminates the need for external
ajustment.
鈥?Supply voltage : 9V and 12V operation.
Specifications
Maximum Ratings
at Ta = 25藲C
Parameter
Maximum supply voltage
Pin1 input voltage
Pin1 input current
Allowable power dissipation
Operating temperature
Storage temperatrure
Symbol
VCCmax
VIN1
VIN1
Pd max
Topr
Tstg
DC
Conditions
SANYO:MFP24S
Ratings
14
+65
鹵1.5
400
鈥?0 to +65
鈥?5 to +150
Unit
V
Vp-p
mA
mW
Ta鈮?5藲C
藲C
藲C
Operating Conditions
at Ta=25藲C
Parameter
Recommended supply voltage
Operating supply voltage range
Symbol
VCC
VCCop
Conditions
Ratings
12
8.5 to 12.75
Unit
V
V
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquaters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
53098HA (KT) No.4091-1/7
